Sealed Enclosure Systems
Congratulations! You have just purchased one of the most advanced
subwoofers in the history of car audio. Your KICKER Solo-Baric is the latest
in KICKER s trend-setting Solo-Baric line, designed and engineered to
deliver the ultimate in low bass performance and unmatched durability.
Thanks for buying KICKER
These enclosures combine KICKER's award-winning Solo-Baric subwoofers
with computer designed and human-fine-tuned enclosures. They offer a
level of bass performance never before thought possible from a commer-
cially available enclosure. The HS Series enclosures are covered in a Ca a ta a lyzed
Polyuretha a ne for protection and pre-loaded with either a Solo-Baric SL5 or
SL7 woofer.
KICKER HS enclosures are engineered to provide the best bass response
when mounted in the rear hatch or trunk.
M M odel
Woofer
H H S S 1 1 2 2 L L 5 5
S12L5
H H S S 1 1 2 2 L L 7 7
S12L7
NOTE:
*The two ohm unit should be used with the KX Series Class D amplifiers KX550.3, KX700.5, KX400.1,
and KX600.1. It is not recommended for use with any KX two or four channel amplifiers.
The four ohm unit should be used with any KX Series two or four channel amplifier. It is not rec-
ommended for use with any KX Series Class D amplifiers.
HS12L5 / HS12L7
. Enjoy.
Installation Instructions
FRONT
Move enclosure around and mount it
Specifications
Imp.
Power
Handling
(Watts)
*2,4
600
*2,4
750
S
REAR HATCH
or TRUNK
where it sounds best to you.
Top
Bottom
Depth
Depth
(In., cm)
(In., cm)
7 7 -11/16,19.53 1 1 4 4 , 35.56
7 7 -11/16,19.53 1 1 4 4 , 35.56
Height
Width
(In., cm)
(In., cm)
1 1 4 4 -5/8, 37.15
1 1 6 6 , 40.64
1 1 4 4 -5/8, 37.15
1 1 6 6 , 40.64
Advertisement
Table of Contents
Related Manuals for Kicker HS12L5
Summary of Contents for Kicker HS12L5
- Page 1 Sealed Enclosure Systems Congratulations! You have just purchased one of the most advanced subwoofers in the history of car audio. Your KICKER Solo-Baric is the latest in KICKER s trend-setting Solo-Baric line, designed and engineered to deliver the ultimate in low bass performance and unmatched durability.
- Page 2 Mounting After determining the best mounting position, check carefully in the areas where the mounting brackets will go. Make very sure that the mounting screws will not puncture the gas tank, brake lines, wire harnesses, etc., or interfere with any mechanical items on the underside of the chosen mount- ing surface.
- Page 3 (1) year from date of original purchase from an authorized Kicker Dealer, unless this product is labeled “B Stock”, in which case it is warranted for ninety (90) days from date of purchase. Should service be necessary under this warranty for any reason due to manufac- turing defect or malfunction during the warranty period, Stillwater Designs will replace or repair (at its discretion) the defective merchandise with equivalent merchandise at no charge.
