Preparation Before Operation
Indoor unit
I I I I I Setting the air purifying filters
1
Open the front grille.
G Hold the grille by the tabs on the two sides
and lift it until it stops with a click.
(about 60°)
2
Pull out the air filters.
G Push upwards the
tab at the center of
each air filter, then
pull it down.
3
Set the air purifying filters.
G Attach an air purifying filter to each air filter.
(See page 12 "Care and cleaning")
4
Set the air filters in their original
positions and close the front grille.
G Operation without air filters may result in
troubles as dust will accumulate inside the
indoor unit.
NOTE
Tips for saving energy
G Be careful not to cool the room too much.
Keeping the temperature setting at a
moderate level helps save energy.
Recommended temperature setting
For cooling: 26°C – 28°C
G Cover windows with a blind or a curtain.
Blocking sunlight and air from outdoors
increases the cooling effect.
G Clogged air filters cause inefficient
operation and waste energy. Clean them
once in about every two weeks.
8
I I I I I Setting the clock
1
Press
.
AM
2
Press
to set the clock to the present
TIMER
time.
PM
G Holding down (
rapidly increases or decreases the time display.
3
Press
.
PM
I I I I I Turn the breaker ON
G Turning ON the breaker opens the flap, then
closes it again. (This is a normal procedure.)
Please note
G The air conditioner always consumes 15 – 35
watts of electricity even while it is not operating.
G If you are not going to use the air conditioner for a
long period, for example in spring or autumn, turn
the breaker OFF.
G Use the air conditioner in the following conditions.
Mode
Operating conditions
Outdoor temperature : 21 to 46 °C
Indoor temperature : 18 to 32 °C
Indoor humidity
: 80% max.
COOL
Outdoor temperature : 21 to 46 °C
Indoor temperature : 18 to 32 °C
DRY
Indoor humidity
: 80% max.
is displayed.
AM
blinks.
) or (
) button
blinks.
(Now the clock is set.)
If operation is continued out of this range
• A safety device may work to stop the
operation.
(In multi system, it may work to stop
the operation of the outdoor unit only.)
• Condensation may occur on the
indoor unit and drip.
• A safety device may work to stop the
operation.
• Condensation may occur on the
indoor unit and drip.
