Genie TriloG 1500 Product Manual

P R O D U C T S P E C I F I C A T I O N S
PRODUCT DESIGN
Motor Type: DC, 140 volts
Drive: Direct Drive Screw
Lighting System: Two 100 Watt bulbs with integrated motion detector
Color: Stone Gray (Pantone Q716-1-3)
Assembled in USA
MOTOR & ELECTRICAL
Direct Drive System: Direct connection from motor to screw drive
Power: 1 HPc*
Application: Any residential garage door as follows: sectional doors
up to 14 ft high; one-piece doors up to 8 ft high
Adjustable Lift Force Level: 9 electronic settings - factory set to typical
steel residential garage door - single or double wide
Lubrication: No lubrication under normal conditions
Voltage: 120 Volts, 60 Hz, 5 Amps
Length of power cord: Model 4064 - 44 in, Model 4064H - 68 in
Type of power cord: 3 prong
Opener Minimum Operating Temperature: -40° F, -40° C
Opener Maximum Operating Temperature: 158° F, 70° C
DRIVE & RAILS
Rail Type: C-Channel
Standard Rail: 112.5" rail for 7 foot doors
Rails Available: C-channel rails available, fully assembled for doors up
to 7 ft, 8 ft, and 10 ft high. Two-piece rails with center hanger support
for doors up to 12 ft and 14 ft high.
Drive Type: Direct motor driven steel screw system
LIGHTING SYSTEM
Recommended bulbs: Two 100 Watt (maximum) incandescent bulbs
Light Activated: Via motion detector, wall console or opener activation
Light On: 4 minutes
POWERHEAD BOX CONTENTS
TriloG 1500 Powerhead model 4064/4064H
™
Owner's Manual
One 3-button remote
One wall console
Safe-T-Beam ® System and wiring
Assembly hardware
RAIL PACKAGE
Outer: Stretch wrapped for weather protection
Color Code: Blue-screw
INSTALLATION
Headroom Clearance Required: 1.5 inches
Limit Setting: Electronic push button
Force Setting: Automatic with electronic adjustability
* 1 Horsepower Comparable (HPc) designates that this garage door opener meets
Genie's lifting force specification for 1 horsepower garage door openers.
** + /– 0.5 inches per second. Speed will slow with one-piece doors
To find a sales center:
1-888-SLS-CNTR
To find a dealer:
1-800-OK-GENIE
For customer service:
1-800-35-GENIE
www.GenieCompany.com
One Door Drive
Mt Hope, OH 44660 USA
PRODUCT CERTIFICATIONS
UL and CUL approved
DIMENSIONS AND WEIGHT
Powerhead: L - 16.8" x W - 10.0" x H - 6.9", Weight - 11 lbs
Assembled Powerhead and 7 ft Rail: Total length - 10.5 ft, 26.5 lbs
Powerhead Boxed: 19" x 10.5" x 11", 19.5 lbs
All rails are stretch wrapped.
7 ft door Rail: 112.5" x 1.75" x 3.25" - 15.5 lbs
8 ft door Rail: 124.75" x 1.75" x 3.25" - 16.5 lbs
10 ft door Rail: 148.75" x 1.75" x 3.25" - 19.5 lbs
12 ft door: two-piece rail: 86.75" x 1.75" x 3.25" - 25 lbs
14 ft door: two-piece rail: 98.75" x 1.75" x 3.25" - 27.5 lbs
Powerhead Pallet Size: 32
Rail Pallet Size: 32
STANDARD ACCESSORIES
One 3-button remote
Wall console
REMOTE SPECIFICATION
System Design: Intellicode ® Access Security System
Remote Size: 2.75" x 1.62" x .73" without clip
Frequency: Auto Seek Frequency (315 and 390 MHz)
Range: 500 ft open field. Per UL recommendations, remote should be
used within line of sight of garage door.
Minimum Operating Temperature: -40° F, -40° C
Maximum Operating Temperature: 158° F, 70° C
Battery Used: CR2032
STANDARD WARRANTIES
Lifetime Motor Warranty: see manual for details
Lifetime Drive Screw Warranty: see manual for details
5 Year Parts Warranty: see manual for details
1 Year Accessories Warranty: see manual for details
GenieSense™ MONITORING & DIAGNOSTIC TECHNOLOGY
Force Profiling technology delivers the power needed at every
movement of the door.
Powerhead intelligence captures performance data.
Safety monitoring system will stop movement of the door when
significant changes occur.
ADDITIONAL INTELLIGENCE & SAFETY
Safe-T-Beam Security System
®
Intellicode ® Access Security System
Sure-Lock System
™
OPERATION**
Door Opening Speed – factory set: 12 in/second @ 30 – 60 lbs
Door Opening Speed – maximum: 12 in/second @ 30 – 60 lbs
Door Closing Speed – factory set: 8.5 in/second
Door Closing Speed – maximum: 8.5 in/second
D E A L E R S E R V I C E S
Your Genie Professional Line sales person or Wayne-Dalton Genie
® ®
Centers are available to answer any questions you have on this or any
Genie ® Professional Line product. Call us to set up an appointment to view
this innovative and profit-driving product today.
© 2011 The Genie Company. Genie, Intellicode, Safe-T-Beam and the Genie logo are registered
trademarks and TriloG, GenieSense, and SmartSet are trademarks of GMI Holdings, Inc., dba
The Genie Company. Consistent with our policy of continuing product improvement, we reserve
the right to change product specifications without notice or obligation. HomeLink is a registered
trademark of Johnson Controls. Car2U is a trademark of Lear Corporation.
P999-907 15M 4/11 JAR
4064/4064H TriloG 1500
™
D I R E C T D R I V E S C R E W G A R A G E D O O R O P E N E R
Sales
®
FOR PROFESSIONAL USE
TriloG 1500
™
The Bes t in Op ener Technolog y
Featuring
1HPc*
