Serial Number Decal
BELT/CHAIN/SCREW DRIVE
GARAGE DOOR OPENER MODELS:
2562, 2568, 3022, 3024, 3042, 3062 , 3064, 4024, 4042, 4062,
4064, 5042, SC1200, CB1000, CB1200
PROGRAMMING,
OPERATION &
MAINTENANCE
MANUAL
Includes INTELLICODE® Remote Control. Safe-T-Beam® system must be installed to close the door. For use only with
residential One-Piece or Sectional Overhead Garage Doors. Homelink® and Car2U® compatible
STOP
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER
HOMEOWNER: SAVE THIS MANUAL FOR FUTURE REFERENCE
To reduce the risk of injury to persons or damage to property, use this opener only with a one-piece or sectional residential door.
Por réduire le risque de blessures ou de dommages materials, utilisez cet ouvre-porte uniquement pour une porte à section ré sidentielle.
©2015 The Genie® Company, the Genie Logo, Intellicode® and Safe-T-Beam®, are trademarks of GMI Holdings, Inc. d/b/a The Genie® Company.
All other trademarks are property of their rightful owners. Consistent with our policy of continuing product improvements, we reserve the right to change product speci cations without
prior notice or obligations. HomeLink is a registered trademark of Gentex Corporation. Car2U is a registered trademark of Lear Corporation.
Need help or have questions?
For answers and assistance,
visit www.GenieCompany.com
or call Customer Service at: 1-800-35-GENIE
WARNING
AVERTISSEMENT
PRE-PROGRAMMED
REMOTE
INCLUDED
FOR QUICK
& EASY
INSTALL
38209502755
38267502755

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2568 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Genie 2568

Summary of Contents for Genie 2568

  • Page 1 Por réduire le risque de blessures ou de dommages materials, utilisez cet ouvre-porte uniquement pour une porte à section ré sidentielle. ©2015 The Genie® Company, the Genie Logo, Intellicode® and Safe-T-Beam®, are trademarks of GMI Holdings, Inc. d/b/a The Genie® Company.

  • Page 2: Table Of Contents

    If you are a homeowner/end user and Remote Battery Replacement ......15 need help or have questions: Light Bulb Replacement ........16 call 800-35-GENIE. Adjustment Guides ........16-17 Or visit: www.GenieCompany.com Do not return product to the store. Locating Safe-T-Beam® Pairs ......18 Alternate language manuals available at: www.GenieCompany.com...

  • Page 3: Safety Information

    Safety Information OVERVIEW OF POTENTIAL HAZARDS READ THIS SAFETY INFORMATION Garage doors are large, heavy objects that move with the help of springs under high tension and electric motors. Since moving objects, springs under tension, and electric motors can cause injuries, your safety and the safety of others depend on you reading the information in this manual. If you have questions or do not understand the information presented, call your nearest trained door system technician or visit our website at www.GenieCompany.com.

  • Page 4: Important Installation Instructions

    POUR RÉDUIRE LES RISQUES DE BLESSURES GRAVES VOIRE MORTELLES LIRE ET SUIVRE ATTENTIVEMENT TOUTES LES INSTRUCTIONS D’INSTALLATION ET DE FONCTIONNEMENT AINSI QUE TOUTES LES CONSIGNES DE SÉCURITÉ. Si vous avez des questions ou si vous ne comprenez pas une instruction, veuillez contacter directement The Genie Company. •...

  • Page 5: Features

    Features Begin here ONLY AFTER completing assembly and installation of the opener. Review the Assembly and Installation Poster to ensure all steps have been performed. Visit www.GenieCompany.com to download a printable le. SAFETY FEATURES OPENER FEATURES Safe-T-Beam® (STB) Non-Contact Intellicode® Reversing System An encryption system that enhances the security Puts an invisible beam across the door open-...

  • Page 6: Wall Console Features

    Wall Control Features One of the following wall controls will be included. NOTE: Wall consoles from other manufacturers may not work with this new opener. Use only the wall control provided with this unit. See warning. SERIES II WALL CONSOLES Open/Close Button Opens and closes door from inside garage.

  • Page 7: Programming Overview

    Programming Overview NOTE: Before programming the operator, check to make sure NOTE: The 3 programming buttons are for programming ONLY. there are no objects in the garage door opening. These buttons should NOT be used to operate the opener once the Required Programming section has been successfully completed.

  • Page 8: Programming Information

    La tendeur DOIT être engagée dans le chariot AVANT de 1-800-35-GENIE or visit www.GenieCompany.com. régler les limites. Voir le poster d’installation (si fourni) ou appelez le service clientèle au 1-800-35-GENIE ou visitez le NOTE: If carriage has NOT been engaged to carriage, do so now. site www.GenieCompany.com.

  • Page 9: Opening Garage Door (Up Limit)

    Programming Information Opening Garage Door (Up Limit) NOTE: Beginning with garage door closed is recommended but not necessary. READ AND UNDERSTAND STEPS 6-9 BEFORE PROCEEDING 9. Press and release the program/set button—both LEDs 6. Press and hold the UP arrow button (+) for two seconds ash blue and then go o . or until the long LED comes on blue.

  • Page 10: Wall Control Operation

    Wall Control Operation Force Control Contact Reverse Test NOTE: The limit and Force settings MUST BE COMPLETED before The force controls are automatically set when the wall control is used performing the Contact Reverse Test. for the rst time with garage door opener. The door MUST complete one full cycle, from full open to full close and then, full close to full 12.

  • Page 11: Remote Control Programming

    Remote Control Programming REMOTES Slowly press and release the remote button two times. The opener LEDs will ash and go o , indicating it has been NOTE: THE REMOTE CONTROLS INCLUDED WITH THIS OPENER, HAVE successfully programmed to the remote. BEEN PRE-PROGRAMMED AT THE FACTORY FOR YOUR CONVENIENCE.

  • Page 12: Programming Keypad

    Programming Wireless Keypad (Optional on some models) Tip: Program Keypad before mounting. Keypad Overview: Synchronizing Keypad to Door 1. Press PROGRAM SET button two seconds until the round LED turns blue, then release. The long purple LED will blink. PRGM 2.
  • Page 13 Programming Wireless Keypad (Continued) Door Operation with Wireless Keypad: Mounting Keypad The keypad MUST be mounted within sight of the garage door(s) at To open and close a single door with the Keyless Entry Pad, enter least ve feet above the oor and clear of any moving door part. the PIN number and press Up/Down Key (enter).

  • Page 14: Programming Vehicle Remotes

    1. Press and release button 1 again. C. Release the button being held in step B and wait for the LED to stop ashing. This button is now set for Genie. Repeat Step 2 for second Genie Opener.

  • Page 15: Clearing Memory For Remotes

    Clearing Remotes CLEARING MEMORY OF REMOTES Press and hold the UP (+) and DOWN (–) button at the same NOTE: Clearing memory of remotes from the powerhead will clear ALL time, until both LEDs ash blue and go o . programmed remotes and wireless keypads.

  • Page 16: Maintenance And Adjustments

    Maintenance and Adjustments For help, call customer service at: 1-800-35-GENIE or visit www.GenieCompany.com IMPORTANT SAFETY INSTRUCTIONS IMPORTANTES CONSIGNES DE SÉCURITÉ WARNING AVERTISSEMENT POUR RÉDUIRE LE RISQUE DE BLESSURES GRAVES VOIRE MORTELLES, TO REDUCE THE RISK OF SEVERE INJURY OR LIRE ET COMPRENDRE TOUTES LES INSTRUCTIONS.

  • Page 17: Regular Maintenance

    Maintenance and Adjustments (continued) Regular Maintenance C. Safe-T-Beam (STB) System Check ® Basic monthly maintenance tasks include: Check that both the RED and GREEN LEDs are ON steady. This indicates • Contact Reverse Test the system is working properly. If both LEDs are not ON steady, check •...

  • Page 18: Light Bulb Replacement

    Replace old light bulb(s) with new. • DO NOT use light bulbs with greater than 100 watt rating. • Powerlift 900, GPower 900, DuraDrive, Model 2568 and Model 5042 require light bulbs of no more than 60 watts. CFL or LED bulbs may be used.

  • Page 19: Resetting Travel Limits

    Maintenance and Adjustments Speed Settings (DC motors only except 5042) Press and hold both up and PRGM Speed settings are pre-programmed at the factory for the down arrow buttons until maximum speed. Speed settings should not need adjustment round LED turns RED, release BLUE buttons.

  • Page 20: Locating Safe-T-Beam® Pairs

    Maintenance and Adjustments Multiple Garage Doors LOCATING SAFE-T-BEAM® PAIRS • NEVER position Safe-T-Beam® modules where signals will cross. Transmitter (RED LED) and Receiver (GREEN LED) • Place the Transmitter (Red LED) Safe-T-Beams on adjacent doors facing in opposite directions. NOTE: Direct sunlight creates interference with Safe-T-Beam ® Receiver (Green LED). STB modules CAN be positioned further away from the door opening if necessary to avoid sunlight but no further o the wall to maintain alignment with the Transmitter (Red LED) module.

  • Page 21: Troubleshooting

    Troubleshooting Need help or have questions? DO NOT RETURN to the store. Visit www.genicompany.com or call Customer Service at 1-800-35-GENIE. PROBLEM: WHAT TO DO: Opener does NOT • Turn Sure-Lock™ OFF See page 4. • Check power source. operator when wall – Plug a lamp into outlet used for powerhead. If lamp works, power source is OK.

  • Page 22: Operation

    Troubleshooting Troubleshooting OPERATION (continued) PROBLEM WHAT TO DO • Be sure all door fasteners are tight. Noisy operation. • Be sure garage door is in good repair, properly lubricated and balanced. • Be sure opener is in good repair. Door opener runs • Check operating condition of door. Door may need professional repair/adjustment. slow. • Is this opener installed on a one-piece door? This opener is not designed to operate a one-piece door. POWERHEAD LEDS Powerhead LED Solution Possible Problem Round LED Long LED Normal operation. None required. Check power supply. No response from unit.

  • Page 23: One Piece Door Installation

    One Piece Door Installation ATTACHING DOOR BRACKET TO DOOR FRAME ATTACHING DOOR ARM TO DOOR BRACKET 1a. Using the bracket as your guide, mark the hole positions on the door 2a. Screw drive models: frame. Center the bracket on the door, as high as possible, preferably One-piece doors must be connected to a straight door arm as shown.

  • Page 24: Warranty

    Limited Warranty GMI Holdings, Inc. d/b/a The Genie Company (“Seller”) warrants to the original purchaser of the Models 2562, 2568, 3022, 3024, 3042, 3062, 3064, 4024, 4042, 4062, 4064, 5042, SC1200, CB1000, or CB1200 garage door opener (“Product”), subject to all of the terms and conditions hereof, that the Product and all components thereof will be free from defects in materials and workmanship for the following period(s) of time, measured from the date of purchase: MOTOR/GEARBOX –...
