Electrical
Shock
Hazard
Plug into a grounded
3 prong outlet.
Do not remove
ground
prong.
Do not use an adapter.
Do not use an extension
cord.
Failure
to follow
these
instructions
can result in
death,
fire,
or electrical
shock.
1. Plug into a grounded 3 prong outlet.
2. Press POWER to start the air purifier. An indicator light will
turn on.
3. Press POWER to stop the air purifier. The indicator light will
turn off.
Fan Speed
Press FAN SPEED until the indicator light comes on for the
desired speed.
FAN SPEED
RESULT
Low
Best product sound
Medium
Slower cleaning power
High
Moderate cleaning power
Turbo
Maximum cleaning power
Sleep Mode
Press SLEEP MODE to set. Sleep mode runs on Low fan speed
for 8 hours and then returns to previously selected setting. To exit
before 8 hours, press SLEEP MODE, FAN SPEED, or POWER.
Control Lock
The Control Lock locks the controls to prevent unintended
changing of the settings when the air purifier is on or off.
1. Press and hold SLEEP MODE for 5 seconds to lock. The
Control Lock indicator light will turn on. (No selection can be
made.)
2. Press SLEEP MODE for 5 seconds to unlock. The Control
Lock indicator light will turn off. Now selections can be made
and the unit can be turned on or off.
Filter Status Lights
The pre-filter and HEPA filter status lights will help you know
when to change your filters. The green status lights will move
from New to Replace at preset intervals. When the red Replace
status light is flashing, replace the filter as indicated. See "Filter
Replacement"
in the "Air Purifier Care" section.
AIRPURIFIER CARE
A
B
A
A. Release tabs
B. Controls
C. Front grille
C
D
E
FG
D. Pre-filter
E Bottom slot
E. HEPA filter
G. Mainframe assembly
1. Press POWER to turn off the air purifier.
2. Unplug air purifier or disconnect
power.
3. Place fingers on the front release tabs. Gently push the tabs
in and pull the front grille forward to remove it.
4. Remove both filters and set aside. Do not try to wash and
reuse either the HEPA filter or the pre-filter.
5. Clean the air purifier with a soft, damp cloth.
6. Gently wash the front grille in soapy water.
NOTE: The grille is not dishwasher
safe.
7. Reassemble the filters as shown in previous illustration.
8. Place the bottom tabs on the front grille into the bottom slots
in base of the air purifier. Push the top of the grille forward
until the grille locks into place.
9. Plug in air purifier or reconnect power.
10. Press POWER to start the air purifier.
NOTE: The filter indicator lights on top of the air purifier will glow
when it is time to replace either the pre-filter or the HEPA filter.
For the most efficient operation of the air purifier, under normal
conditions it is recommended
that you replace the pre-filter every
3 months and the HEPA filter every year. See "Replacement
Filters" in the "Assistance
or Service" section.
1. Press POWER to turn off the air purifier.
2. Unplug air purifier or disconnect
power.
3. Place fingers on the front release tabs. Gently push the tabs
in and pull the front grille forward to remove it.
4. Remove and replace the indicated filter. Install the new HEPA
filter in the same direction shown by the arrow located on the
filter frame. Install the new pre-filter by placing it on the tabs.
NOTE: Do not try to wash and reuse either the HEPA filter or
the pre-filter.
5. Place the bottom tabs on the front grille into slots in the base
of the air purifier. Push the top of the grille forward until the
grille locks into place.
