Cisco Nexus 6001 Switch
S e n d d o c u m e n t a t i o n c o m m e n t s t o n e x u s 6 k d o c s @ c i s c o . c o m .
The Cisco Nexus 6001 power supplies support both 110 and 220-volt (V) inputs.
Note
Caution Never leave a power supply slot empty. If you remove a power supply, replace it with another one. If you
do not have a replacement power supply, leave the non functioning one in place until you can replace it.

Fan Modules

The Cisco Nexus 6001 has three individual fan modules supporting four fans per module. Fan modules
are hot-swappable. Fan modules operate in a 3+1 redundancy mode. If a fan fails, the unit can run
indefinitely with only 3 operational fans. Fan options need to be configured with the base chassis. The
Cisco Nexus 6001 switch supports front-to-back and back-to-front airflow.OIR is supported on the fan
tray.
Table 1-2
Part Number
N6K-C6001-FAN-F=
N6K-C6001-FAN-B=
Caution You must order all fan modules and power supplies in the same chassis so that they have the same
direction of airflow with coolant air entering the chassis from the cold aisle and exhausting to the hot
aisle.

Transceivers

The Cisco Nexus 6001 supports a wide variety of 1, 10, and 40 Gigabit Ethernet connectivity options.
This section includes the following topics:
•
•

1 and 10 Gigabit Ethernet SFP+ Transceiver Support Matrix

Cisco SFP
FET-10G
Cisco SFP-10G-SR
Cisco SFP-10G-LR
Cisco Nexus 6000 Series Hardware Installation Guide
1-4
Table 1-2 lists the fans that you can order with a Cisco Nexus 6001 switch.
Fan Modules for the Cisco Nexus 6001 switch
Power Supply
Cisco Nexus 6001 Fan Module, Front-to-Back (Port Side Exhaust)
Airflow, spare
Cisco Nexus 6001 PSU module, 100-240VAC 1100W, Back-to-Front (Port
Side Intake) Airflow, Spare
1 and 10 Gigabit Ethernet SFP+ Transceiver Support Matrix, page 1-4
40 Gigabit Ethernet QSFP+ Transceiver Support Matrix, page 1-5
Description
10-Gbps SFP+ module for Cisco Nexus 2000 Series to Cisco Nexus 5000
Series connectivity
10GBASE-SR SFP+ module (multimode fiber [MMF])
10GBASE-LR SFP+ module (single-mode fiber [SMF])
Chapter 1 Overview
OL-15902-01
