IBM system x3200 Product Manual page 11

An affordable single-socket, dual-core server with high performance and data protection for small
and medium businesses
Disk drive technology
Integrated disk controller
# of disk drives supported per port
Integrated RAID controller
Optional RAID controllers supported
# of adapter slots total / available
# of PCI-E x8 slots (4GBps)
# of PCI-E x1 slots (500MBps)
# of legacy 33MHz legacy PCI slots
# of video ports
Video controller
Video memory
Maximum video resolution at 32-bit
color
Gigabit Ethernet controller
# of Gigabit Ethernet ports
# of RS485 ports
# of serial ports
# of parallel ports
# of PS/2 mouse ports
# of PS/2 keyboard ports
# of USB 2.0 ports
Integrated systems management
controller
Optional systems management
adapter
Light path diagnostics support
Predictive Failure Analysis support
Power supply size
# of power supplies standard /
maximum
Hot-swap/redundant power supported
# of fans/blowers standard / maximum
Hot-swap/redundant fans supported
Heat emitted: minimum / maximum
Please see the Legal Information section for important notices and information.
x3200 Specifications
3.5-inch hot-swap SAS/SATA (24X/24Y,
2DX/2DY, 44X/44Y, 4DX/4DY, 56X/56Y,
57X/57Y, 5FX/5FY, 5GX/5GY, 62X/62Y,
6BX/6BY, 64X/64Y, 6DX/6DY
Four-port LSI 1064e SAS/SATA—hot-
swap models
LSI 1064e (hot-swap models only) for RAID 0/1/1E
LSI 1064e (simple-swap models only) for RAID 0/1/1E
1024 x 768 x 24-bit color at 85Hz
6 external ports (2 front, 4 rear), plus 1 internal connector for tape drive
Remote Supervisor Adapter II SlimLine
Processors, memory, voltage regulator modules (VRDs), HDDs, PCI-E slots, and fans
430W universal, autoswitching (56X/56Y,
57X/57Y, 5FX/5FY, 5GX/5GY, 64X/64Y,
6DX/6DY)
1 / 2 (56X/56Y, 57X/57Y, 5FX/5FY,
5GX/5GY, 64X/64Y, 6DX/6DY)
Yes / Yes (56X/56Y, 57X/57Y, 5FX/5FY,
5GX/5GY, 64X/64Y, 6DX/6DY)
3 / 3 (plus one fan per power supply)
630 / 1784 (model-specific)
3.5-inch simple-swap SATA (22X/22Y,
2BX/2BY, 32X/32Y, 3BX/3BY, 42X/42Y,
43X/43Y, 4BX/4BY, 4CX/4CY, 52X/52Y,
5BX/5BY)
Four-port SATA (via chipset)—simple-
swap models
1
5 / 5
1 full-height/full-length
1 full-height/full-length
3
1
ATI Radeon ES1000
16MB SDRAM
Broadcom BCM5721
1 (rear)
None
8
2 (rear)
1 (rear)
1 (rear)
1 (rear)
Yes (mBMC)
None
400W universal, autoswitching (all other
models)
1 / 1 (all other models)
No (all other models)
No
11
