However, you may program any two Function Keys on any Master Key page to manually
trigger the Assignable 12V and Relay "On" or "Off" by creating a sequence consisting of
just one step if desired, which would be either the "Relay On" or "Relay Off" command.
The Assignable relay can be configured as a "momentary contact" by issuing the "Relay
On" command as the first step, then the "Relay Off" command as the second step in the
sequence. See page 13 of the IntelliFile II Reference manual for more information.
3G. Utilities

ID Code

The IntelliControl Tabletop Remote features four DIP switches located behind the batteries
inside the battery compartment.
Select the "Utilities" Tab in the IntelliFile II software and make sure that the Unit ID on the
Tabletop Remote matches the Unit ID configuration in the software. It really doesn't matter
which way the DIPswitches are set, as long as they are set the same. Up to 16
IntelliControls maybe used within a 100ft radius if each unit is set to a different Unit ID
Code.

Volume Reset

The "Volume Reset" feature enables you to configure the system to automatically lower
the volume to minimum and raise it to any desired level when the "System Off" key is
pressed.
Note: This feature will only work if the Preamp's "Volume Up" and "Volume Down"
commands are taught to the "Volume Up" and "Volume Down" keys on the Default page.
In the IntelliFile II software, program the appropriate commands to the "Default" page as
described in "Step 3 – Program Function Key IR Commands and Sequences". Then,
press the Edit key on the "Utilities" page, and adjust the appropriate slider to set the
duration of the "Volume Down" and "Volume Up" commands in order to reconfigure the
system to turn on to a comfortable level.

IR Routing

Enabling the "IR Routing" feature allows you to program up to eight components with
identical IR codes. Note: A complete description of the IR Routing feature is detailed in the
®
IntelliFile II help file.
When IR routing is enabled, the system will operate as follows:
1. All "Component Power" commands as well as "Function Key IR" and "Function Key
Sequence" commands taught to the selected Master Key page are issued from that
Master Key's flasher port only.
2. When enabled, "IR Routing" effects IR codes issued from Master Key flasher ports
1 through 8 only!
3. Commands taught to the Function Keys on Master Key pages 9 and 10 as well as all
Commands on Library pages 1 and 2 come out of all flasher ports, even with "IR
Routing" enabled.
4. "TV Power", "Preamp Power", "TV Input Select", "Preamp Select", and "Preamp
