Furuno SEARCHLIGHT SONAR CH-250 Specification Sheet

Furuno 10.4" color lcd display searchlight sonar

Hide thumbs Also See for SEARCHLIGHT SONAR CH-250:

Download this manual See also: Operator's Manual, Installation Manual

High definition active matrix color LCD

Choice of frequency: 60, 88 or 150 kHz

Blackbox system configuration allows use of

optional CRT or LCD monitors

Target lock on a fish school or L/L position

for a designated fishing area

Pulse length automatically switched with

range to optimize performance on all ranges

A specific color can be shown in white to

enhance the echo level display

Instant selection of eight different

operational modes

Audible target detection

freeing the operator from a

continuous display watch

Customized fishing menu

SEARCHLIGHT SONAR

The future today with FURUNO's electronics technology.

FURUNO ELECTRIC CO., LTD.

9-52 Ashihara-cho, Nishinomiya City, Japan Telephone: +81 (0)798 65-2111

Telefax: +81 (0)798 65-4200, 66-4622, 66-4623

10.4" COLOR LCD DISPLAY

Model

CH-250

Catalogue No. E-381c

TRADE MARK REGISTERED

MARCA REGISTRADA
