RGA624PF – Hotpoint 24" Free-Standing Gas Range
Dimensions (in inches)
24
26*
39-3/4
36
39-1/2
*Depth including up-front
angled control panel.
Specification Revised 10/03
430211
®
Installation Information (in inches)
Recommended gas and electric supply locations.
3
5
33
2
2
Check local codes
before making
connections
24-3/8
30" Min.
13"
Max.
0
18" Min.
6
36
18
Electrical
Connection
3
Area
9
Recommended gas
2
hook-up locations behind
range. Gas fittings and
shut-off valve should
not protrude more than
24-3/8
2" from the wall to allow
range to fit against the wall.
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before
installing, consult installation
instructions packed with product
for current dimensional data.
Note: LP conversion kit is NOT
required for this model.
All Hotpoint ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
CERTIFIED
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hotpoint RGA624PF
Summary of Contents for Hotpoint RGA624PF
- Page 1 ® RGA624PF – Hotpoint 24" Free-Standing Gas Range Dimensions (in inches) Installation Information (in inches) Electrical Rating: 120V, 60Hz, 5A Recommended gas and electric supply locations. Installation Information: Before 24-3/8 installing, consult installation 30" Min. instructions packed with product for current dimensional data.
- Page 2 ® RGA624PF – Hotpoint 24" Free-Standing Gas Range Features and Benefits • Recessed Lift-Up Cooktop with Easy-Clean Subtop • Standard Clean Oven • 4 Standard Burners • Rectangular Burner Grates • Standing-Pilot Ignition System • Push-To-Turn Controls • Separate Broiler Drawer (with Tip-Down Door) •...
