Hotpoint RGA720EK Installation Information

RGA720EK – Hotpoint 20" Free-Standing Gas Range

Dimensions (in inches)

NOTE: Recommended gas
hook-up locations behind
range. Gas fittings and
shut-off cock should NOT
protrude more than 2" from
the wall to allow the range
to fit against the wall.
2"
2-1/2"
12"
14"
8"
30"
3"
8"
2"
2"
Gas
Hookup
Area
Specification Created 7/05
430214
®
Installation Information (in inches)
20-3/8"
30" Min.
13"
Max.
1/4"
18" Min.
36"
8" Electrical
Connection
Area
8"
5"
20-3/8"
20"
40-1/2"
2" Minimum
distance to
walls above
36"
the cooktop
on each side
41"
Electrical Rating: 120V, 60Hz, 5A
26-1/2" Depth
with door closed
Installation Information: Before
(includes handle)
installing, consult installation
instructions packed with product
for current dimensional data.
Note: LP conversion kit is required for
this model.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
CERTIFIED
