Summary of Contents for Crunch PowerOne P1-12D2
- Page 1 Powerone SUBWOOFERS P1-12D2 / P1-12D4...
- Page 2 CRUNCH POWERONE SERIES CAR AUDIO SUBWOOFERS Congratulations on your purchase of the new Crunch PowerOne subwoofer system. The PowerOne subwoofer series are a bargain with good build quality and accurate bass reproduction. 12-Inch DVC Subwoofer Dual 2-Ohm and Dual 4-Ohm Voice Coils...
-
Page 3: Enclosure Materials
SUBWOOFER INSTALLATION AND WIRING DIRECTIONS Enclosure Materials Typically, 5/8” or 3/4” MDF (Medium Density Fiber Board) is best for most applications. 3/4” MDF is recommended. Enclosure Build Materials Connecting joints need to be glued and screwed to ensure no air escapes and joints do not separate under high pressure. Mitered and rabbit joints also help to ensure the enclosure joints are secure. -
Page 5: Glossary Of Terms
Glossary of Terms The energy losses of relative damping (ratio of stored to dissipated energy or ratio of reactive to resistive energy). Free air resonance of driver in Hz. Qms Mechanical Q. Vas Volume of air equivalent to driver from the rest position. Cms Mechanical compliance of a loud speaker piston. - Page 6 P1-12D2 DVC 2-Ohms PARALLEL SERIES 4-Ohms 1-Ohm PARALLEL COILS / PARALLEL SUBS 0.5-Ohms SERIES COILS / PARALLEL SUBS 2-Ohms...
- Page 7 P1-12D4 DVC 4-Ohms PARALLEL SERIES 8-Ohms 2-Ohms PARALLEL COILS / PARALLEL SUBS 1-Ohm SERIES COILS / PARALLEL SUBS 4-Ohms...
- Page 8 SUBWOOFER DIMENSIONS...
- Page 9 Maxxsonics Limited Warranty As the manufacturer of Maxxsonics, MB Quart, Autotek, Crunch and Hifonics car audio products, Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase.
- Page 10 PART#: F2/11...
