Summary of Contents for Sundown Audio SAX-100.4

  • Page 1 Owner's manual SAX-100.4...
  • Page 2 Visit us online at http://www.sundownaudio.com WARRANTY: Your new Sundown Audio amplifier is covered by a 2 year limited warranty if purchased from an authorized Sundown Audio dealer. This warranty does not cover improper installation, accidental damage, misuse, abuse, improper wiring, operation of unit outside of listed specifications, or any product that has been modified or repaired by anyone other than Sundown Audio.

  • Page 3: Specifications

    Features 4/3/ 2 Channel Bridgeable Class-AB Amplifier MOSFET PWM Power Supply Stable Into 4 Ohms Bridged or 2 Ohms Stereo Load 12dB Octave Electronic Crossover Slope Variable Subsonic Filter Independent 1/2 Channel High Pass Filter Variable with x 10 Range Selectable Switch Variable 1/2 Channel Low Pass Filter with HPF/FULL/LPF Selectable Switch Independent 3/4 Channel Low Pass Filter Variable...

  • Page 4: Bass Boost

    Crossover adjustment Amplifiers are equipped with built-in switchable electronic crossovers. The filters will operate on both channels and also in bridged mode. When using the amplifier in bridged mode, only 4 ohm speaker load should be used. When using a separate amplifier to power subwoofers, it is preferable to switch amplifier x-over to high pass to stop bass distortion of full range speakers and increase system efficiency.
  • Page 5 RCA Connection GAIN SUBSONIC BASS BOOST BASS REMOTE FULL 50Hz 500Hz 30Hz 250Hz 35Hz 120Hz 18dB 0.2V 10Hz 100Hz RANGE SIGNAL INPUT Channel 1/2 PROTECTION FREQ. Channel 3/4 RANGE FULL 0.2V 10Hz 100Hz 50Hz 500Hz 50Hz 1KHz 35Hz 120Hz 18dB GAIN SUBSONIC BASS BOOST POWER...

  • Page 6: Channel Stereo

    Speaker Connection 2 Channel Bridged CH1-MONO SUBWOOFER BRIDGE Left/Ch1 Right/Ch2 Speaker Impedance 4~8 ohms CH2-MONO Left/Ch3 Right/Ch4 SUBWOOFER SPEAKER 4 Channel Stereo BRIDGE Left/Ch1 Right/Ch2 Speaker Impedance 2~8 ohms Left/Ch3 Right/Ch4 SPEAKER 6 Channel Tri Mode CH5-MONO SUBWOOFER BRIDGE Left/Ch1 Right/Ch2 Speaker Impedance 4~8 ohms...

  • Page 7: Trouble Shooting

    Trouble Shooting This power amplifier has protection features to prevent any damages from misuse or faulty conditions. If the unit senses excessive heat, short circuited speakers or overload, the protection indicators will light, and the system will be turned off. In order to check the occurred problem, you should turn all levels down and all power off and carefully check the installation for wiring mistakes or short.
