Summary of Contents for Sundown Audio SAZ-1000D
- Page 1 Owner's manual SAZ-1000D SAZ-1500D SAZ-3000D...
-
Page 2: Warranty
Visit us online at http://www.sundownaudio.com Your new Sundown Audio amplifier is covered by a 2 year limited warranty if purchased from an authorized Sundown Audio dealer. This warranty does not cover improper installation, accidental damage, misuse, abuse, improper wiring, operation of unit outside of listed specifications, or any product that has been modified or repaired by anyone other than Sundown Audio. - Page 3 Features SAZ-1000D Digital Class-D Linkable Mono Block Amplifier Double Sided Through Hole Epoxy PCB 1 Ohm Stability Daisy-Chain Through Output RCA Efficiency : 86% @ 4 ohm, at 100Hz 24dB/Oct Variable Crossover Multi-Way Protection Circuitry (Thermal/Over Current/Speaker Short/Speaker DC Protection)
-
Page 4: Specifications
Specifications SAZ-1000D Rated power output -RMS power, 2 ohm linkable/dual mono ------ -RMS power, 1 ohm mono ------------------------ -RMS power, 2 ohm mono ------------------------ -RMS power, 4 ohm mono------------------------- Signal to Noise Ratio ----------------------------------- Low pass frequency crossover --------------------- Subsonic filter ----------------------------------------------... -
Page 5: Rca Connection
RCA Connection SAZ-1000D / SAZ-1500D / SAZ-3000D Single Amp Input Connection IN PUT BR OUT GAIN CLASS-D LINKABLE MONO BLOCK amplifier IN PUT BR IN HEAD UNIT Dual Amp Input Connection "MASTER UNIT" IN PUT BR OUT GAIN CLASS-D LINKABLE MONO BLOCK amplifier... -
Page 6: Power Connection
Power Connection SAZ-1000D POWER FUSE To +12V DC GROUND to REMOTE Turn-on from HEAD UNIT BATTERY CAR STEREO HEAD UNIT SAZ-3000D POWER GROUND to REMOTE Turn-on from HEAD UNIT This amplifier is not supplied with internal fusein itself. CAR STEREO HEAD UNIT Make sure you install in-line fuse holderfrom the + terminal of battery. - Page 7 Single Amp Power and Speaker Connection SAZ-1000D POWER FUSE To +12V DC GROUND to REMOTE Turn-on from HEAD UNIT BATTERY CAR STEREO HEAD UNIT POWER FUSE To +12V DC GROUND to REMOTE Turn-on from HEAD UNIT BATTERY CAR STEREO HEAD UNIT...
- Page 8 Single Amp Power and Speaker Connection SAZ-3000D POWER To +12V DC GROUND to REMOTE Turn-on from HEAD UNIT CAR STEREO HEAD UNIT BATTERY POWER To +12V DC GROUND to REMOTE Turn-on from HEAD UNIT CAR STEREO HEAD UNIT BATTERY SPEAKER Caution This amplifier is not supplied with internal fuse in itself.
- Page 9 Dual Amp Power and Speaker Connection SAZ-1000D "MASTER UNIT" POWER FUSE To +12V DC GROUND to REMOTE Turn-on from HEAD UNIT BATTERY CAR STEREO HEAD UNIT "SLAVE UNIT" POWER FUSE To +12V DC GROUND to REMOTE Turn-on from HEAD UNIT...
- Page 10 Dual Amp Power and Speaker Connection SAZ-3000D "MASTER UNIT" POWER GROUND to REMOTE Turn-on from HEAD UNIT BATTERY CAR STEREO HEAD UNIT Use 8 Gauge(AWG) wire cable "SLAVE UNIT" POWER GROUND to REMOTE Turn-on from HEAD UNIT CAR STEREO HEAD UNIT BATTERY Using a dual amplifier configuration, the MASTER amplifier has total control over the SLAVE amplifier .
-
Page 11: Troubleshooting
Trouble Shooting This power amplifier has protection features to prevent any damages from misuse or faulty conditions. If the unit senses excessive heat, short circuited speakers or overload, the protection indicators will light, and the system will be turned off. In order to check the occurred problem, you should turn all levels down and all power off and carefully check the installation for wiring mistakes or short. - Page 12 MADE IN KOREA...
