Dell™ XPS™ M1730 Service Manual
Before You Begin
Internal Card With Bluetooth Wireless Technology
Hard Drive
Memory
Coin-Cell Battery
Hinge Cover
Keyboard
Communication Cards
Display Assembly
LCD Camera
GamePanel
Palm Rest
Fan
Wireless Sniffer Board
Optical Drive
ExpressCard Reader
Processor Thermal-Cooling Assembly
Processor
Speakers, Audio Connectors, and Consumer Infrared
Memory Card Reader
Video Card and System Board
Power Management Controller Board - Hall
Battery Latch Assembly
Flashing the BIOS
Pin Assignments for I/O Connectors
Notes, Notices, and Cautions
NOTE:
A NOTE indicates important information that helps you make better use of your computer.
NOTICE:
A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
CAUTION:
A CAUTION indicates a potential for property damage, personal injury, or death.
Information in this document is subject to change without notice.
© 2007 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, and XPS are trademarks of Dell Inc.;Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under
license. Intel and Pentium are registered trademarks of Intel Corporation; Microsoft, Windows, and Windows Vista are either trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
Model PP06XA
September 2007 Rev. A00
