Summary of Contents for Epson LabelWorks Safety Kit

  • Page 1 User’s Guide...
  • Page 2 Display Turn on/off Print Repeat design Add symbols Add a special effect Delete Shift Select/Enter Caps lock Add an accented letter Add a space...

  • Page 3: Table Of Contents

    Contents Welcome Customizing Your Labels ........3 .
  • Page 4 FCC Compliance Statement....35 Epson America, Inc. Limited Warranty ..36 Trademarks ......38...

  • Page 5: Welcome

    Welcome With the tapes listed on the back cover, you can do even more: Your LabelWorks Safety Label Kit lets you ■ Organize stuff in your kitchen, bathroom, create custom labels to help you identify and every room of your house. hazards, emergency supplies, warning ■...

  • Page 6: Getting Started

    Getting Started 2. Insert 6 AA alkaline batteries, positioning the + and - ends as shown. Your LabelWorks printer requires 6 AA batteries (not included). An optional AC adapter is also available (C52CB73020). Follow the instructions in this section to insert the batteries and tape cartridge.

  • Page 7: Using The Optional Ac Adapter

    Using the optional AC adapter Inserting a label cartridge Plug in the AC adapter as shown. 1. Remove any slack from the label. Remove the rear cover. Caution: Make sure you use only the AC adapter designed for your LabelWorks printer (C52CB73020) or damage may occur.

  • Page 8: Removing A Label Cartridge

    3. Insert the cartridge and press it down Removing a label cartridge firmly until it snaps into place. 1. Remove the rear cover. 2. Hold the cartridge by the tabs, and lift it straight up. 4. If there is excess label, feed the end through the tape guide slot.

  • Page 9: Creating Labels

    Creating Labels Creating long labels The number of characters and symbols you Enter text to begin creating your label. Then can enter is limited, but you can use the follow the suggestions for adding length if following techniques to create longer labels: necessary.

  • Page 10: Saving Labels

    Saving Labels Enhancing Your Labels You can store up to 50 saved labels at a time. Get creative by adding symbols or frames to your labels and selecting the right font.. After you finish creating your first label, press to create another label (the label Tip: Use clear labels for a professional look.
  • Page 11 Symbols Prohibition Household Food Sports Activity Enhancing Your Labels...
  • Page 12 Occasion Shipping Electrical Animals Zodiac Emoticons Enhancing Your Labels...
  • Page 13 Measurement Metric Abbreviation Punctuation Parentheses Math Enhancing Your Labels...
  • Page 14 Currency DoubleFigure Greek Office Safety Facility Enhancing Your Labels...

  • Page 15: Adding Frames

    Adding frames Frames include borders and symbols for activities and other purposes. 1. Press 2. Press to scroll through the frames or enter the frame number to jump directly to a frame, then press to select the frame you want to use. Note: To quickly remove a frame from a label, press type the number “0”, then press twice.
  • Page 16 Enhancing Your Labels...

  • Page 17: Changing The Font Size

    Changing the font size Changing the font You can change the size of the letters, Choose a font that fits your needs. numbers, and symbols on your label. 1. Press 1. Press 2. Press to scroll through the fonts, then 2.

  • Page 18: Changing The Font Style

    Printing Labels Changing the font style Personalize your label text with bold, italic, 1. Press to print the current label. shadow, and outline effects. The length of the label and the number 1. Press of copies shows on the display while the 2.

  • Page 19: Printing Multiple Copies

    Customizing Your Labels Printing multiple copies You can print up to 9 copies of a label on one You can customize your labels by creating label. This lets you create longer labels for special effects, such as vertical and mirrored increased visibility on larger items.

  • Page 20: Adding Space Between Characters

    Adding space between characters Increasing print density You can add extra space between the letters, You can make the print on your labels darker numbers, and symbols on your label. if necessary. 1. When the power is off, press Print density appears on the display. 2.

  • Page 21: Adding Letters With An Accent Mark

    ■ Press repeatedly to scroll through the Customizing the length of labels first group of marks, then press You can specify the length of your labels (up select the desired mark. to 15 in.) ■ Press , then press repeatedly 1.

  • Page 22: Creating Sequentially Numbered Labels

    Safety Applications for 1. Press Labels 2. Press until you see Mirror print, then press to select it. LabelWorks labels can be used in many different ways to improve home or office Creating sequentially numbered safety. labels ■ Label emergency supplies and You can create a label, and then print information numbered copies of it.

  • Page 23: Special Format Labels

    Special Format Labels Flag labels Flag labels provide a large surface for You can use custom labels to identify high- multiple lines of text. A vertical line marks voltage cables and shut-off switches. the center of the flag to help wrap the cable Reflective, glow-in-the-dark, or fluorescent evenly.

  • Page 24: Wrapped Labels

    Flag label tips Wrapped labels ■ When labeling cables with a flag label, Wrapped labels are useful for tight spaces set a specific length for the label. If you where flags are too large or only a short use the “Auto” feature, the text will be too identifier is necessary.

  • Page 25: Index Tab Labels

    ■ Repeat a single line of text on multiple Index tab labels lines to improve readability. You can print index tab labels for labeling ■ Use multiple labels on a single cord to folders and dividers. include more information. Note: Index tabs are only available when ■...

  • Page 26: Barcode Labels

    Barcode labels The following barcode settings can be modified: LabelWorks can create barcode labels in a variety of formats. These barcodes can be Width: Adjusts the space between the bars used for inventory management and asset of the barcode. tagging. Ratio: Adjusts the width of the wide bars in Supported formats: CODE39, CODE128, ITF, the barcode (2, 2.5, or 3 thin bar widths).

  • Page 27: Adjusting The Display

    Adjusting the Display Cleaning the Printer You can adjust the following display settings: Use a dry, soft cloth or, for stubborn stains, a moist cloth that has been wrung dry. Backlight: Turns the backlight of the display on or off. Caution: Never use chemicals or solvents such as benzine, thinner, alcohol, or a chemical Contrast: Adjusts the density of the fonts on...

  • Page 28: Storing Your Kit

    Storing Your Kit LabelWorks LW-400 Two LabelWorks cartridges LabelWorks Six AA batteries AC adapter (optional) (available separately) Storing Your Kit...

  • Page 29: Solving Problems

    Solving Problems Seq. num. only 1 Sequence numbers have already been set. You can only enter one sequence number per label. If you have a problem with your LabelWorks, Text too long Entered text is too long for the check the display or the troubleshooting specified label length.

  • Page 30: Problems And Solutions

    If the same cancel, press any other button). message appears, turn the power off again and contact Epson for The product will be reset. technical support. Power is on but no images appear on the...
  • Page 31 ■ ■ If you are using the AC adapter, make Make sure the rear cover is closed. sure that it is securely connected to both Characters do not print properly the wall outlet and the product. ■ Make sure the tape cartridge is correctly ■...

  • Page 32: Epson Technical Support

    Days and hours of support are subject to change without notice. Toll or long distance charges may apply. Recycling Epson offers a recycling program for end of life products. Please go to www.epson.com/ recycle for information on how to return your products for proper disposal.

  • Page 33: Purchase Supplies And Accessories

    Registration Purchase supplies and accessories Epson offers a wide array of tapes for To receive special offers and updates on new multiple uses. For a complete list of available tapes, make sure you register your tapes, including additional widths, visit LabelWorks printer.

  • Page 34: Specifications

    ■ Power supply - Model: C52CB73020 Do not spill liquid on the product or use the optional AC Manufacturer: Seiko Epson Corp. product with wet hands. adapter Input: AC100-240 V, 0.3 A, 50-60Hz ■ Do not open any covers on the product other than Output: DC 6.5 V, 1.5 A...
  • Page 35 ■ Continuing to use the product may result in Operate the keyboard gently. damage or injury. ■ Take care not to cut your fingers when cutting a ■ To avoid injury, keep your fingers away from the tape with scissors. label exit slot when printing or using the cutter.

  • Page 36: Tape Cartridges

    ■ ■ Remove dead batteries promptly. Place the AC adapter and power cord to avoid abrasions, cuts, fraying, crimping, and kinking. Do ■ Do not heat batteries or throw them in fire or not place heavy objects on top of the AC adapter or water.

  • Page 37: About Printed Labels

    ■ Connect the equipment into an outlet on a circuit Epson is not responsible for any damage or loss caused different from that to which the receiver is by labels or adhesive. connected. ■...

  • Page 38: Epson America, Inc. Limited Warranty

    Epson property. The replacement your Epson product prove defective during the product or part may be new or refurbished to the Epson warranty period, please call the Epson Connection standard of quality, and, at Epson’s option, may be (562) 276-7245 (U.S.
  • Page 39 Epson is not responsible for warranty OR CONSEQUENTIAL DAMAGES RESULTING FROM THE service should the Epson label or logo or the rating label USE OR INABILITY TO USE THE EPSON PRODUCT, or serial number be removed or should the product fail...

  • Page 40: Trademarks

    This warranty gives you specific legal rights and you may have other rights which vary from jurisdiction to jurisdiction. To find the Epson Authorized Reseller nearest you, visit our website at http://www.epson.com. To find the Epson Customer Care Center nearest you, visit http://www.epson.com/support.
  • Page 41 Font size Frame Design number Line number The black marks Battery level indicate features you are using...
  • Page 42 LabelWorks tapes available at www.epson.com/LabelWorks 1/4 inch 3/8 inch 1/2 inch 3/4 inch (6 mm) (9 mm) (12 mm) (18 mm) Glow-in- LC-5ZBU1 the-Dark Reflective LC-4SBR1 LC-4YBR1 LC-5SBR1 LC-5YBR1 LC-4BWV9 LC-5BKP9 LC-5WBN9 LC-4WBN9 Standard LC-5SBE9 labels LC-4NWT5 LC-5TWN9 LC-5TBN9 LC-5TKN9...
