CyberResearch GDR 15L User Manual

Gdr 15l series 15.1" flat-panel tft lcd display with resistive touchscreen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
Displays
GDR 15L Series
15.1" Flat-Panel TFT LCD Display
GDR 15L: 15.1" Rugged Desktop LCD Monitor
GDR 15L-TR: GDR 15L with Resistive Touchscreen
USER'S MANUAL
VER. 1.1 • MAR 2005
No part of this manual may be reproduced without permission
CyberResearch
, Inc.
®
www.cyberresearch.com
25 Business Park Dr., Branford, CT 06405 USA
203-483-8815 (9am to 5pm EST) FAX: 203-483-9024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDR 15L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CyberResearch GDR 15L

Summary of Contents for CyberResearch GDR 15L

  • Page 1 ® Displays GDR 15L Series 15.1″ Flat-Panel TFT LCD Display GDR 15L: 15.1″ Rugged Desktop LCD Monitor GDR 15L-TR: GDR 15L with Resistive Touchscreen USER’S MANUAL VER. 1.1 • MAR 2005 No part of this manual may be reproduced without permission CyberResearch , Inc.
  • Page 3 CyberResearch, Inc. In no event will CyberResearch, Inc. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 ® GDR 15L Series CyberResearch Displays Intentionally Blank GDR 15L Series...

  • Page 5: Table Of Contents

    ® CyberResearch Displays GDR 15L Series Table Of Contents 1. Introduction ......1 2. Unpacking ......2 3.
  • Page 6 ® GDR 15L Series CyberResearch Displays ©Copyright 2005 CyberResearch, Inc.

  • Page 7: Introduction

    . What makes the GDR 15L different? The GDR 15L is a high quality, Ultra-Bright TFT LCD display with a resolution of 1024x768. Sleek yet solid, our GDR Series displays feature a two-piece cast aluminum shell with low-profile rubber buttons, designed to withstand the shock and vibration of industrial and vehicle use.

  • Page 8: Unpacking

    ® GDR 15L Series CyberResearch Displays Unpacking Along with the GDR 15L rugged TFT, each box should contain the following: 1. Universal AC/DC Power Supply 2. 2-meter VGA Connector Cable 3. 3-pin IEC Power Lead 4. 9-pin Serial Connector Cable 5.

  • Page 9: Connecting To A Computer

    Using the following simple instructions, the GDR 15L will be installed and configured within about five minutes. On the bottom of the GDR 15L, there are two ports—a 15-pin VGA port, and a power jack. One end of the VGA cable will already be connected to the VGA port when the unit is shipped.

  • Page 10: Image Control And Adjustment

    • Try increasing the refresh rate above 60 Hz. Do not exceed 75 Hz. • Fine-tune the Brightness, Contrast and Sharpness functions using the On-Screen Control. 4.3 The GDR 15L is an extremely bright display, operating at 400 nits (400 cd/m ). We strongly recommend that, unless the unit is used in very bright lighting conditions, the brightness be reduced to around 60 to 70% using the On-Screen Control.
  • Page 11 Displays GDR 15L Series 4.4 Changing the screen resolution: The GDR 15L can operate in full screen at either SVGA (800x600) or VGA (640x480) .The unit cannot operate at any resolution higher than 1024x768. In order to step down resolution, simply select the “Display” icon in the Control Panel, chose “Settings,”...
  • Page 12 ® GDR 15L Series CyberResearch Displays Display Display Type LCD flat panel Video Input Types Standard analog VGA (15-pin) Screen Size (viewable area, diagonal) 15.1" 06" to 15" Display Filter Screen Size 15" to 18" Display Brightness 250 nits (High-Bright)

  • Page 13: Power Supply

    ® CyberResearch Displays GDR 15L Series Power Supply Power Supply Form Factor External (fully enclosed) Nominal Input Voltage(s) 110/220VAC Input Voltage Range(s) 100...240VAC Input Frequency 50/60Hz Power Supply Input Connector NEMA standard male PC cord socket Output Voltage(s) +12VDC DC Input Power Info...
  • Page 14 ® GDR 15L Series CyberResearch Displays 154.5mm 60mm 94.5mm 309mm ©Copyright 2005 CyberResearch, Inc.

  • Page 15: Cleaning And Maintenance

    A friendly customer service technician will arrange for a full refund, replacement, exchange, or credit. If you have any questions about your GDR 15L, call our toll-free number in the USA (1-800-341-2525), call worldwide (203-483-8815), send a fax to (203-483-9024), or email our applications engineers at techsupport@cyber- research.com.
  • Page 16 ® GDR 15L Series CyberResearch Displays ©Copyright 2005 CyberResearch, Inc.

  • Page 17: Product Service

    Signal connections and programming are the two most common sources of difficulty. CyberResearch support personnel can help you solve these problems, especially if you are prepared for the call.
  • Page 18 ® GDR 15L Series CyberResearch Displays Intentionally Blank GDR 15L Series...
  • Page 19 CyberResearch, Inc. will, at its option, repair or replace the defective item under the terms of this warranty, subject to the provisions and specific exclusions listed herein.
  • Page 20 ® GDR 15L Series CyberResearch Displays Intentionally Blank GDR 15L Series...
  • Page 22 CyberResearch, Inc. 25 Business Park Drive Branford, CT 06405 USA P: (203) 483-8815; F: (203) 483-9024 www.cyberresearch.com...

This manual is also suitable for:

Gdr 15l-tr
