Installing the Charge-Only Cradle
To install the charge-only cradle,
1.
Place the cradle in the location where it will be used.
2.
Plug the DC power cable from AC adapter into the DC input connector located on the bottom of the
charge-only cradle.
3.
Plug the AC power cable into the AC adapter and into an AC outlet.
The charge-only cradle is ready to be used.
2-30
Assembling and Installing Connectivity Peripherals
DC Power
Input Connector
Figure 2-23. Charge-Only Cradle
