QuickSpecs
Overview
W h a t ' s N ew
Dual optical drive support with
one fixed drive and one modular
bay drive
Mobile Intel Pentium III 1.2
GHz–M, 1.13 GHz-M, or 1.06
GHz-M processor with enhanced
SpeedStep™ technology
Digital Video Editing Port 1394
Easy Access Internet Buttons
A t A G l a n c e
Weighs only 7.6 lb/3.4 kg
1.6 in/4.1 cm thin
15-inch XGA TFT display
128 or 256-MB SDRAM (133
MHz) standard, upgradeable to
1024 MB
Integrated mini PCI 56K V.92
modem plus 10/100 NIC
Complete set of system ports
including two USB port expansion
options, 1394 Digital Video Input
Full-size keyboard
Microsoft Windows XP Pro or
Windows 2000 Professional
preinstalled
Protected by a One-Year,
Worldwide Limited Warranty —
certain restrictions and exclusions
apply. Consult the Compaq
Customer Support Center for
details.
What's Special
Modular Bay which enables
simultaneous use of up to two
optical drives, supports a second
battery, or floppy drive
Magnesium display enclosure
DA-10978
North America — Version 6 — February 18, 2002
Compaq Evo Notebook N180
1
Advertisement
Related Manuals for Compaq Evo N180
Summary of Contents for Compaq Evo N180
- Page 1 QuickSpecs Compaq Evo Notebook N180 Overview W h a t ' s N ew Dual optical drive support with one fixed drive and one modular bay drive Mobile Intel Pentium III 1.2 GHz–M, 1.13 GHz-M, or 1.06 GHz-M processor with enhanced SpeedStep™...
-
Page 2: Standard Features
The Evo™ Notebook N180 comes with four Easy Access Buttons designed to increase customer productivity by B u t t o n s providing one-touch access to helpful Compaq information, favorite Internet destinations, files, or applications. TouchPad P o i n t i n g D e v i c e... - Page 3 QuickSpecs Compaq Evo Notebook N180 Standard Features I n t e r f a c e s PC Card Slot 1 Type I, II USB 1.1 Connectors Digital Video Port 1394 Parallel SPP/ECP standard interface; (DB25 connector) PS/2 Style Mouse or Keyboard...
- Page 4 The Evo Notebook N180 8-cell Lithium-Ion battery provides up to four hours of battery life; up to six hours achieved using optional additional Modular Bay battery. NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 4:05 (hr:min) were achieved running the eTesting Labs Inc.'s BatteryMark Test version 4.0.1 on an N180 with an Intel Pentium III-M 1 GHz CPU, 15-inch XGA panel, 128-MB RAM, 20-GB HDD, CD, 8-cell Lithium-Ion battery, and NIC/modem.
- Page 5 QuickSpecs Compaq Evo Notebook N180 Standard Features N a m i n g C o n v e n t i o n The Etymology of a Model name: DA-10978 North America — Version 6 — February 18, 2002...
- Page 6 QuickSpecs Compaq Evo Notebook N180 Standard Features O D E L S 15-inch color TFT XGA N18P113X520VC25TOL Display Mobile Intel Pentium III 1.13 GHz-M Processor 512-KB, L2 Cache Cache Memory Standard 256-MB SDRAM Memory Maximum 1024-MB SDRAM DVD-ROM drive Fixed Optical Drive...
- Page 7 Windows XP Professional 470030-249 N180P120X530C25TOL Windows XP Professional 470030-255 Additional Evo N180 models are available with the modules listed below through the Built For Your Business , custom-configuration models at www.directplus.compaq.com. Intel Pentium III-M 1.06 GHz Microsoft Windows 2000 Professional DA-10978...
-
Page 8: Useful Accessories
128-MB SDRAM (133 MHz) Memory Module 197897-B25 64-MB SDRAM (133 MHz) Memory Module 197896-B25 (Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only Compaq branded memory modules to ensure compatibility.) Power Lithium-Ion (4.0AH) – Primary Battery 235883-B21... - Page 9 512 MB 256 MB 256 MB 768 MB 256 MB 512 MB 1 GB 512 MB 512 MB Following are memory options available from Compaq: 64-MB Memory Upgrade 197896-B25 128-MB Memory Upgrade 197897-B25 256-MB Memory Upgrade 197898-B25 512-MB Memory Upgrade 238830-B25 DA-10978 North America —...
- Page 10 QuickSpecs Compaq Evo Notebook N180 Storage R I V E U P P O R T Quantity Drive Bay Supported System Drive Support Supported Media 8x DVD-ROM Modular Bay; Removable CD-RW Drive Modular Bay; Removable DVD/CD-RW combo drive Modular Bay; Removable Secondary Battery Modular Bay;...
-
Page 11: Technical Specifications
QuickSpecs Compaq Evo Notebook N180 Technical Specifications Dimensions (H x W x D) System Unit 1.63 x 12.91 x 10.99 in/4.14 x 32.79 x 27.91 cm Weight 15-inch TFT with Li-Ion Battery 7.65 lb/3.47 kg and weight saver Stand-Alone Power Nominal Operating Voltage 14.8 VDC... - Page 12 QuickSpecs Compaq Evo Notebook N180 Technical Specifications Hard Drives Capacity 20-GB 20 GB Height 0.374 in/9.5 mm Width 2.75 in/70 mm Interface ATA-5 Transfer Rate Synchronous (maximum burst) 100 MB/s (Drive Capability) Security ATA Security Seek Time Single Track 2.5 ms...
- Page 13 QuickSpecs Compaq Evo Notebook N180 Technical Specifications Modular Bay Drive DVD/CD-RW Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm Weight 0.74 lb/0.33 kg Center Hole Diameter 1.5 cm Disk Diameter...
-
Page 14: Lithium-Ion Battery Pack
QuickSpecs Compaq Evo Notebook N180 Technical Specifications Center Hole Diameter DVD-ROM Drive (Fixed) 1.5 cm Disc Diameter 12 cm/8 cm Disc Thickness 1.2 mm Track Pitch 0.74 µm Access Times Random < 180 ms DVD Media (typical reads, including settling) Full-Stroke (typical) <... - Page 15 Compaq PCs use genuine Microsoft Windows www.microsoft.com/piracy/howtotell Compaq, Evo, registered United States Patent and Trademark Office. Intel, the Intel Inside Logo, and Pentium are registered trademarks of Intel Corporation. Microsoft, MS and Windows are registered trademarks of the Microsoft Corporation in the U.S. and other countries.
