Autostart ASL-300 Installation Manual

Keyless entry and alarm system
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Guide
Included in the Kit........................... 1
Programmable Features .................. 2
Harness Description......................... 2
Programming Options .................... 4
Adjustment........................................ 6

Included in the Kit

Please review the installation guide before beginning the installation, especially the wiring diagram and the
programming options. It is very important that you familiarize yourself with the programming and operation of
the system, even if you have already installed an alarm system in the past. There are many great new features
that may be overlooked if the manual is not read: you would therefore not maximize the unit's potential. Prior to
the installation, make sure that all the hardware components required to install the system are in the box.
o 1 - Control unit.
o 1 - 2-WAY 6-button LCD transmitter and 1 - FM Antenna (only for TW System)
o 1 - 4-button transmitter for the TW system (2 transmitters for 1-Way System)
o 1 - Siren
o 1 - plug-in L.E.D
o 1 - Hood-pin switch
o 1 - plug-in valet button.
o 1 - 2 pin Wire harness.
o 1 - 5 pin Main harness.
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of the product, be that either damage to the vehicle itself or to the Unit.
This Unit must be installed by a certified technician using all safety devices supplied. Only
registered technicians will be eligible to use the Autostart technical support telephone
service. Please review the Installation Guide carefully before beginning any work
DOC: 1.05
Keyless Entry And Alarm System
_____________________

Table of Contents

The following is a list of components included in the kit:
The kit also includes the following harnesses:
April 12, 2006
Dome Light Delay............................ 7
Retain Accessory Output............... 7
Zone 2 Disable Output .................. 7
Multi-car Operation ........................ 7
Resetting the Module...................... 7
Rate ..................................................... 7
Closing Up ......................................... 8
1 - plug-in shock sensor
o
1 - user guide
o
1 - installation guide.
o
1 - 12 pin principal auxiliary
o
harness
1 - 3 pin connector cable
o
TL
Manufactured in Canada by Autostart
.
