Autostart AS-6105 SH/SR Quick Manual

A U T O M A T I C T R A N S M I S S I O N R E M O T E S T A R T E R & F U L L - F E A T U R E D A L A R M S Y S T E M
I. Learning a Transmitter
The AS-6105 SH/SR Transmitter is not delivered pre-programmed and must be code-learnt after the wiring of the
Module is completed. The system has the ability to learn up to 4 different transmitters, if a fifth Transmitter is learnt, the
code of the first Transmitter in memory will be lost. To erase all Transmitters from memory you must perform a Module
reset.
To program a new transmitter, do the following:
1. Ensure that the Hood is up, that the vehicle is not in Valet Mode and that the Ignition is
•
Hold the Hood Pin-switch down for 4 seconds.
•
Release the Pin-switch. The Parking Lights will come on.
•
While the Parking Lights are on, immediately push and release the Pin-switch again.
The Parking Lights will stay on for up to 20 seconds.
2. Turn the Ignition Key to the
Wait until the Parking Lights go out, then turn the Ignition Key
The L.E.D. will be flashing during the next step.
3. Press the
... until the Parking Lights flash 5 times quickly and the Siren chirps twice.
You can alternatively press the button repeatedly until you see 5 flashes and hear 2 chirps.
4. To exit, close the Hood.
II. Valet Operation
When in Valet Mode, the Module will not carry out any remote start. The Alarm and Starter Kill will be disabled.
The AS-6105 SH/SR is equipped with a protected Push-button Valet Switch requiring the Ignition Key of the vehicle
in order to place the system in and out of Valet Mode. This will make it difficult for potential thieves to steal your vehicle
by hot-wiring your car after merely switching off the Valet.
Getting
1. Turn the Ignition Key to the
2. Within 3 seconds, press and release the Valet button (the L.E.D. will come on and stay lit).
Getting
1. Turn the Ignition Key to the
2. Within 3 seconds, press and release the Valet button (the L.E.D. will go out).
If you try to remote-start the vehicle while it stands in Valet Mode, the Parking Lights will flash once, pause and flash
twice again.
III. Multi-speed Tach Learning
Tach signals may vary from vehicle to vehicle. The AS-6105 SH/SR system is designed to read a wide range of Tach
signals produced by recent Ignition systems. A Tach-learning procedure must be carried out every time a new Unit is
installed.
The procedure for Multi-speed Tach-learning is as follows:
1. Ensure that the Hood is up and that the Ignition is
•
Hold the Hood Pin-switch down for 4 seconds.
•
Release the Pin-switch. The Parking Lights will come on.
•
While the Parking Lights are on, immediately push and release the Pin-switch again.
The Parking Lights will stay on for up to 20 seconds.
2. Press and hold the Brake Pedal and simultaneously press the
The Parking Lights will flash 4 times and the Siren will chirp 4 times.
3. Release the Brake Pedal; start the vehicle. Allow it to reach regular Engine idle speed.
The Parking Lights will go out when the Tach signal is detected.
4. Press and hold the Brake Pedal: if the Parking Lights flash 5 times the Tach signal has been learnt.
The Siren will chirp 1, 2 or 3 times to indicate which Tach mode has been detected.
H.1.00.S.2.00 Rev: 2.00
AS-6105 SH/SR
Quick Installation Guide
IGNITION ON (RUN)
button (or the button), wait 1 second and press the button again
LOCK UNLOCK
Valet Mode
IGNITION ON (RUN)
of Valet Mode
IGNITION ON (RUN)
CA Fb
position.
, then back
OFF ON
position.
position.
.
OFF
and
LOCK UNLOCK
– October 15, 2002
.
OFF
again.
OFF
buttons on the Transmitter.
Manufactured in Canada by Autostart
