MOUNTING METHOD
METHODE DE MONTAGE
Fiberglass panel
Panneau de fibre de verre
Speaker
Haut-parleur
Grille
Gril
"ATTENTION"
Speaker edge is very sharp.
Le bord de l'enciente
est tres tranchant.
WIRING DIAGRAM
DIAGRAMME DE CABLAGE
Main unit
Unite principal
Speed nut (4)
Ecrou de vitesse (4)
Mounting screw (4)
Vis de Montage (4)
Flush mount tweeter installation
Installation affleurante de tweeter de bati
Tweeter
Fiberglass panel
Panneau de fibre de verre
Angle mount tweeter installation
Installation de tweeter de bati d'angle
Angle mount
bracket
Tweeter
Mounting screw (2)
Vis de Montage (2)
Speaker
Haut-parleur
L
R
Part No. CMCS71 -011205
Speed nut (2)
Ecrou de vitesse (2)
Tweeter
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Clarion CMCS71 -011205
Summary of Contents for Clarion CMCS71 -011205
- Page 1 Speaker edge is very sharp. Tweeter Ecrou de vitesse (2) Le bord de l'enciente est tres tranchant. Mounting screw (2) Vis de Montage (2) WIRING DIAGRAM Speaker DIAGRAMME DE CABLAGE Tweeter Haut-parleur Main unit Unite principal Part No. CMCS71 -011205...
- Page 2 Speaker Mounting Template Calibre De Support D'orateur 4.5mm (3/16") 4- Holes Tweeter flush mount template Calibre de bati d'eclat de tweeter Part No. CMCS71-011205T...
