Speaker Mounting Template
Calibre De Support D'orateur
4.5mm (3/16")
Dia
8- Holes
MOUNTING METHOD
METHODE DE MONTAGE
Subwoofer
Grille
Gril
WIRING DIAGRAM
DIAGRAMME DE CABLAGE
Amplifer
Amplificateur
"ATTENTION"
Subwoofer edge is very sharp.
Le bord de l'enciente
est tres tranchant.
Fiberglass panel
Panneau de fibre de verre
Speed nut (8)
Ecrou de vitesse (8)
Mounting screw (8)
Vis de Montage (8)
Subwoofer
Part No. CMSW -011205 & T
