CDE-9845RB/CDE-9845RR
CDE-9843R/CDE-9843RM
• OWNER'S MANUAL
Please read before using this equipment.
• BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor Gebrauch des Gerätes.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• ISTRUZIONI PER L'USO
Si prega di leggere prima di utilizzare il attrezzatura.
• ANVÄNDARHANDLEDNING
Innan du använder utrustningen bör du läsa igenom denna användarhandledning.
ALPINE ELECTRONICS MARKETING, INC.
1-1-8 Nishi Gotanda,
Shinagawa-ku,
Tokyo 141-0031, Japan
Phone 03-5496-8231
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
7300 Warden Ave., Suite 203, Markham,
Ontario L3R 9Z6, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
Meiyi Printing Factory, Dalian, China
No. 28 Chang Qing Street, Xi Gang District, Dalian, China
RDS MP3/WMA CD Receiver
RDS MP3 CD Receiver
FM/MW/LW/RDS CD Receiver
CDE-9841R
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Phone 03-9769-0000
ALPINE ELECTRONICS GmbH
Frankfurter Ring 117
80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
R
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone 01-48638989
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
Designed by ALPINE Japan
Printed in China (Y)
68-00493Z98-A
EN
DE
FR
ES
IT
SE
Advertisement
Table of Contents
Related Manuals for Alpine CDE-9845RB
Summary of Contents for Alpine CDE-9845RB
- Page 1 Si prega di leggere prima di utilizzare il attrezzatura. • ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning. ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. 1-1-8 Nishi Gotanda, 6-8 Fiveways Boulevarde Keysborough,...
-
Page 2: Table Of Contents
ENGLISH The CDE-9845RX model that appears in this Manual represents the CDE-9845RB and CDE-9845RR models. The CDE-9843RX model that appears in this Manual represents Contents the CDE-9843R and CDE-9843RM models. Operating Instructions Sound Setting Adjusting Bass/Treble/Balance (Between Left and Right)/Fader (Between Front and Rear)/ WARNING Defeat ............ -
Page 3: Operating Instructions
Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR Alpine Service Centre for repairing. - Page 4 We recommend not using these accessories on discs such instrument, then insert the disc again. played in Alpine CD players. Centre Hole Centre Hole Disc...
- Page 5 Finalize the CD-R/CD-RW if necessary, and attempt playback again. About media that can be played. The following table shows which discs can be played on which models. CD-TEXT CDE-9845RB/CDE-9845RR CDE-9843R/CDE-9843RM CDE-9841R Use only compact discs with the label side showing the CD logo marks below. CDE-9845RB/CDE-9845RR/CDE-9843R/CDE-9843RM...
-
Page 6: Getting Started
Connectable to Steering Remote Control Interface Box Detaching and Attaching the Front Panel You can operate this unit from the vehicle's control unit when an Alpine Steering Remote Control Interface Box (optional) is connected. For details, contact your Alpine dealer. Detaching Turn off the unit power. -
Page 7: Radio
Radio Automatic Memory of Station Presets Press BAND repeatedly until the desired radio band is displayed. SOURCE/ TUNE/ POWER A.ME BAND Press and hold TUNE/A.ME for at least 2 seconds. The frequency on the display continues to change while the automatic memory is in progress. The tuner will automatically seek and store 6 strong stations in the selected band. -
Page 8: Rds
Recalling Preset RDS Stations Press F/SETUP so that the “F” indicator lights up. CDE-9845RX Press 1/AF to activate the RDS mode. BAND Press F/SETUP to activate the normal mode. The “F” indicator goes out. Make sure that the “F” indicator light goes out, then press the preset button in which your desired RDS station is preset. -
Page 9: Pi Seek Setting
PI SEEK Setting PTY (Programme Type) Tuning Press and hold F/SETUP for at least 2 seconds. Press F/SETUP so that the “F” indicator lights up. Press g or f to select “PI SEEK” (CDE- Press 3/PTY to activate the PTY mode, while the 9845RX) or “PISK”... -
Page 10: Receiving Traffic Information While Playing Cd Or Radio
Receiving Traffic Information While Playing Priority News CD or Radio This function allows you to preset to give priority to the News programme. You will never miss the News programme as the unit Press TA so that the “TA” indicator lights up. automatically gives priority to the News programme whenever it begins broadcasting, and interrupts the programme you are currently Press g and f to select a traffic information... -
Page 11: Cd/Mp3/Wma
MP3/WMA Play Display The folder number and file number will be displayed as described The following table shows which discs can be played on which below. models. CDE-9845RX: CD-TEXT CDE-9845RB/CDE-9845RR CDE-9843R/CDE-9843RM F01 T03 10'15 CDE-9841R Folder number Elapsed time Playback... -
Page 12: Repeat Play
Repeat Play Scanning Programmes Press F/SETUP to illuminate the “F” indicator. Press F/SETUP to illuminate the “F” indicator. Press 4 ( ) within 10 seconds to play back Press 6 ( ) within 10 seconds to activate the repeatedly the track being played. Scan mode. -
Page 13: File/Folder Name Search (Concerning Mp3/Wma) (Cde-9845Rx/ Cde-9843Rx Only)
File/Folder Name Search (concerning MP3/ Quick Search (CDE-9845RX/CDE-9843RX only) WMA) (CDE-9845RX/CDE-9843RX only) You can search for tracks (files). You can display and search for the folder and file name while Press F/SETUP to illuminate the “F” indicator. listening to the file currently being played back. Press and hold 3 /PTY within 10 seconds for at Press F/SETUP to illuminate the “F”... - Page 14 Supported playback sampling rates and bit rates Order of files The unit plays the files in the order that the writing software Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz, writes them. Therefore, the playing order may not be the same 16 kHz, 12 kHz, 11.025 kHz, 8 kHz as the order you input.
-
Page 15: Sound Setting
CDE-9843RX/CDE-9841R: Sound Setting • If the MODE/LOUD is not pressed within 15 seconds after selecting the BASS or TREBLE mode, the unit automatically returns to normal mode. CDE-9845RX When the subwoofer mode is set to OFF, its level cannot be adjusted. -
Page 16: Setting The Treble Control
Setting the Treble Control Turning Loudness On/Off You can change the Treble Frequency emphasis to create your own Loudness introduces a special low- and high-frequency emphasis at tonal preference. low listening levels. This compensates for the ear's decreased sensitivity to bass and treble sound. CDE-9845RX: Press CENTER f. -
Page 17: Other Functions
Displayed during playback of a disc with CD Text. Other Functions “NO TEXT” will be displayed when the CD contains no Text data. “ROOT ” is displayed for a folder that does not have a folder name. ID3 tag/WMA tag CDE-9845RX If an MP3/WMA file contains ID3 tag/WMA tag information, the ID3 tag/WMA tag information is displayed (track name, artist... -
Page 18: Titling Discs
Titling Discs Erasing Disc Title It is possible to title your favourite CD's. Press TITLE to select the Title Display. Then, press You cannot input titles on radio station or MP3/WMA discs. again and hold for at least 2 seconds. Press TITLE and select the Title Display. -
Page 19: Setup
9845RX) or press 4 and 3 (CDE-9843RX/CDE-9841R). CDE-9843RX/CDE-9841R Visual Customizing BAND Dimmer Control (CDE-9845RB only) DIMMER AUTO (Initial setting) / DIMMER MANU Set the DIMMER control to AUTO to decrease the illumination brightness of the unit with the head lights of the vehicle ON. This mode is useful if you feel the unit's button lighting is too bright at night. -
Page 20: Mp3/Wma
Otherwise, make sure the rest of your system is CD data only. When a disc contains both CD or the MP3/WMA data, properly connected or consult your authorized Alpine dealer. playback starts from the CD data portion of the disc. - Page 21 Press the c button again for at least 2 seconds. • The CD has been damaged. If the disc still does not eject, consult your Alpine dealer. - Eject the CD and discard it; using a damaged CD in your unit can cause damage to the mechanism.
-
Page 22: Specifications
CAUTION Specifications FM TUNER SECTION Tuning Range 87.5 – 108.0 MHz CLASS 1 Mono Usable Sensitivity 0.7 µV Alternate Channel Selectivity 80 dB LASER PRODUCT Signal-to-Noise Ratio 65 dB Stereo Separation 35 dB Capture Ratio 2.0 dB (Bottom side of player) MW TUNER SECTION Tuning Range 531 –... -
Page 23: Installation And Connections
RCA-type jacks for connection to other units (e.g. amplifier) having RCA connectors. You may need an adaptor to connect other units. If so, please contact your authorized ALPINE dealer for assistance. • Be sure to connect the speaker (–) leads to the speaker (–) terminal. -
Page 24: Installation
Installation Slide the CDE-9845RX/CDE-9843RX/CDE-9841R into the dashboard until it clicks. This ensures that the unit is properly locked and will not accidentally Rubber Cap come out from the dashboard. Install the (Included) Detachable Front Panel. Bracket Hex Bolt Removal (Included) 1 Remove the detachable front panel. -
Page 25: Connections
JASO Antenna Plug (Pink/Black) AUDIO INTERRUPT IN To vehicle phone (Blue/White) REMOTE TURN-ON To amplifier or equalizer (Orange) DIMMER To the instrument cluster illumination lead (CDE-9845RB only) (Red) IGNITION To power antenna (Black) Ignition Key (Blue) POWER ANT (Yellow) BATTERY Battery "... - Page 26 Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.
