360 Systems RC-205 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Remote
Control
Owner's
Manual
MODELS
RC-205
RC-210
RC-220
with
Second Edition
360 Systems
PROFESSIONAL DIGITAL AUDIO
5321 Sterling Center Drive
Village, CA 91361 Phone (818) 991-
0360
Fax (818) 991-1360
Web: http://www.360systems.com
Email:
info@360systems.com
SERIAL NUMBER: ______________
Westlake

Advertisement

loading
Need help?

Need help?

Do you have a question about the RC-205 and is the answer not in the manual?

Questions and answers

Summary of Contents for 360 Systems RC-205

  • Page 1 Remote Control Owner’s Manual MODELS RC-205 RC-210 RC-220 with Second Edition 360 Systems PROFESSIONAL DIGITAL AUDIO 5321 Sterling Center Drive Westlake Village, CA 91361 Phone (818) 991- 0360 Fax (818) 991-1360 Web: http://www.360systems.com Email: info@360systems.com SERIAL NUMBER: ______________...
  • Page 2 It is suggested that only shielded and grounded cables be used to ensure compliance with FCC Rules. Printing history: Software Version 1.2, October 1993 Software Version 1.2, August 1994 Software Version 1.2, March 1997 Copyright 1993 -1997, 360 Systems Printed in the United States of America All rights reserved...

  • Page 3: System Requirements

    STACK operations to the RC-210/220. The RC-205 Mini-Keyboard connects to the Alpha Keyboard port on DigiCart's rear panel. For RC-205, make sure the SETUP MENU — KEYBOARD TYPE is selected to MINI. The RC-210/220 Remote Control models use the Serial Port 2 connector.
  • Page 4 RC-205 MINI KEYBOARD The RC-205 Mini Keyboard provides remote access to all DigiCart functions, plus the full range of up to 104 PRESETS. The RC-205 also allows use of the FIND function for Cut and Stack Names and Indexes. The RC-205 functions in the same manner as a standard AT-type 101 keyboard but does so with fewer keys by doubling up on key functions.
  • Page 5 The RIGHT and LEFT arrows duplicate the functions of the POSITION ARROWS on the DigiCart. FIND OPERATIONS Using the RC-205, you can readily FIND any Cut or Stack by Name or Index number. TO FIND BY INDEX Press the FIND key (F5).
  • Page 6 For Cuts on the current Drive, only enter the last four digits of the Index. For Cuts on other Drives, use the full five-number Index. The " . " separator is not needed with the FIND function. RC-205/210/220 Remote Control Owner's Manual Second Edition...
  • Page 7 DigiCart will FIND the next match in this logical sequence of Drives and Directories. Press PLAY to Play the Cut or enter it into a Stack (see Chapter 4 of your DigiCart Owner's Manual). RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 8 PRESET OPERATIONS The PRESET function lets you assign a Cut or Linear Stack to the RC-205 letter keys. When assigned, the selection will PLAY immediately when you press the associated Hot Key, or PRESET. A-Z are 26 single-stroke Hot Keys. Shift—, Alt— and Ctrl—A-Z may contain 78 additional PRESETS instantly accessed by compound keystrokes.
  • Page 9 Cut or Linear Stack you wish to assign. Press the Left POSITION ARROW to go to the Directory Layer. Press UTILITY MENU (F1) and select ASSIGN PRESET. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 10 Press any assigned key (or Shift—, Ctrl—, or Alt— combination) to play a PRESET. Note: The SETUP MENU'S RESTART MODE — IMMEDIATE or ON COMPLETION — affects the playing of PRESETS. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page 8...
  • Page 11 Item for Follow-On Play. The display will show: X.XXXX (Name) HH:MM:SS Note: The number under ID counts the Items in the QuickStack. The time is total QuickStack duration. Press PAUSE to Play the QuickStack. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page 9...
  • Page 12 QuickStack. The time is total Stack duration. Press ENTER to save the Stack. The display will prompt: LINEAR SELECT WITH ARROWS Use the POSITION ARROWS to select LINEAR or ROTATING. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 13 Press the STACK button (F4) to view a Stack's contents. Step through the list using either the SELECT or POSITION ARROWS. This process may be used to reset the next Item in a ROTATING STACK. Press STACK (F4) again to exit. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 14 For cable runs longer than 25 feet (8 meters), you should connect the DC transformer directly into the rear panel of the Remote Control. This prevents problems resulting from voltage drops or current loss over a long cable run. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 15 If the Remote is connected after the DigiCart's power is turned on, simultaneously press the SEC and FILE XFER (DNET XFER on DigiCart/II Plus) buttons on the DigiCart's front panel. This will "soft boot" the DigiCart and re-initialize the system. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 16 48K AC-2 Note: The information on the bottom line pertains to the current Selection. Complete the entry of the Index number for the Cut you wish to locate. Press ENTER. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 17 Index. The " . " separator is not needed with the FIND function. Repeat as necessary for Follow-On Play or press CANCEL to exit. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 18 Press the PRESET key you wish to assign. NOTE: It is not necessary to Clear a PRESET before reassigning it. Repeat steps 2 and 3 as necessary. Press CANCEL to exit the ASSIGN PRESETS function. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...

  • Page 19: Stack Operations

    Note: The number under ID counts the Items in the QuickStack. The time is total QuickStack duration. Press MAKE PLAYLIST again to release PAUSE and begin playback of the QuickStack. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 20 Note: The Stack Index will end with the letter "L" for Linear Stacks. It will end with the letter "R" for Rotating Stacks. Use CHANGE NAME to give the Stack a new name. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 21 Use the SELECT Arrows to advance the upper line information. You can look ahead to view Index and Name information about all events yet to play in the Stack. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 22 DigiCart end of the cable. A short pig-tail cable with a female coax connector exits from the 9-pin connector hood and is assigned to receive power from the wall mount power supply. RC-205/210/220 Remote Control Owner's Manual Second Edition...
  • Page 23 If the Remote is connected after the DigiCart's power is turned on, simultaneously press the SEC and FILE XFER (DNET XFER on DigiCart/II Plus) buttons on the DigiCart's front panel. This will "soft boot" the DigiCart and re-initialize the system. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...

  • Page 24: Machine Control

    The UP and DOWN arrows duplicate the functions of the SELECT KNOB on the DigiCart. The RIGHT and LEFT arrows duplicate the functions of the POSITION ARROWS on the DigiCart. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 25 Index. For Cuts on other Drives, use the full five-number Index. The " . " separator is not needed with the FIND function. Repeat as necessary for Follow-On Play or press CANCEL to exit. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 26 Index. The " . " separator is not needed with the FIND function. Repeat as necessary for Follow-On Play or press CANCEL to exit. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 27 "Machine 01 not on line". This message is of no consequence.) Note: It is not necessary to Clear a PRESET before reassigning it. Repeat steps 2 and 3 as necessary. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 28 RC-220 will illuminate. Use the SELECT and POSITION Arrows or FIND operations to choose a Cut or Stack. Press ENTER to add the first Item to the QuickStack. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 29 The Play light will begin to blink, indicating more than one Item for Follow-On Play. The display will show: X.XXXX (Name) HH:MM:SS Note: The number under ID counts the Items in the QuickStack. The time is total Stack duration. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 30 Rotating Stacks. Use CHANGE NAME to give the Stack a proper name. (This is best done with the RC-205 Mini-Keyboard.) VIEWING A STORED STACK'S CONTENTS You can check the contents of a Stack before you play it, or even examine it while the Stack is playing.

  • Page 31: Menu Operations

    DigiCart. You can access any MENU function simply by pressing one of the MENU buttons on the RC-220. Please refer to your DigiCart Owner's Manual for detailed information about each MENU function. — + — RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...
  • Page 32 APPENDIX A INTERCONNECTION BETWEEN MODEL RC-220 AND 1 TO 4 DIGICARTS RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997 Page...

  • Page 33: Specifications

    Cable......25 foot (7.5 meters) highly flexible 9 conductor cable. Connects directly to DigiCart/II or RCA-59 Interconnect Cable Assembly. Part No. RCA-59: Interconnect Cable Assembly for connecting RC-220 To 1-4 DigiCart/IIs. RC-205/210/220 Remote Control Owner's Manual Second Edition March 1997...
  • Page 34 Model RC-205 Specifications Operational Features Position Arrows......Select Drives and Directories. (Arrows facing up/down) Select Arrows......Review Cuts by scrolling through Directory listing. (Arrows facing left/right) Presets........"Hot Keys" for rapid playback of 104 pre-assigned Cuts. (Scroll Lock must be on for the PRESET function to work.) Esc Key CANCEL/NO ....Cancels incorrect entries.
