Power Condition Name
Idle_a
Idle_b
Idle_c
Standby_z
Each power condition has a set of current, saved and default settings. Default settings are not modifiable.
Default and saved settings persist across power-on resets. The current settings do not persist across power-on
resets. At the time of manufacture, the default, saved and current settings are in the Power Conditions log
match.
PowerChoice is invoked using one of two methods
• Automatic power transitions which are triggered by expiration of individual power condition timers. These
timer values may be customized and enabled using the Extended Power Conditions (EPC) feature set using
the standardized Set Features command interface.
• Immediate host commanded power transitions may be initiated using an EPC Set Features "Go to Power
Condition" subcommand to enter any supported power condition. Legacy power commands Standby Imme-
diate and Idle Immediate also provide a method to directly transition the drive into supported power condi-
tions.
PowerChoice exits power saving states under the following conditions
• Any command which requires the drive to enter the PM0: Active state (media access)
• Power on reset
PowerChoice provides the following reporting methods for tracking purposes
Check Power Mode Command
• Reports the current power state of the drive
Identify Device Command
• EPC Feature set supported flag
• EPC Feature enabled flag is set if at least one Idle power condition timer is enabled
Power Condition Log reports the following for each power condition
• Nominal recovery time from the power condition to active
• If the power condition is Supported, Changeable, and Savable
• Default enabled state, and timer value
• Saved enabled state, and timer value
• Current enabled state, and timer value
S.M.A.R.T. Read Data Reports
• Attribute 192 - Emergency Retract Count
• Attribute 193 - Load/Unload Cycle Count
16
Power Condition ID
81
H
82
H
83
H
00
H
Description
Reduced electronics
Heads unloaded. Disks spinning at full RPM
Heads unloaded. Disks spinning at reduced RPM
Heads unloaded. Motor stopped (disks not spinning)
