Sony XC-ST70 Brochure

Component / OEM
OUTLINE
The XC-ST70/ST70CE incorporates a next generation
2/3-inch CCD into a new, compact black and white
camera module. The XC-ST70/ST70CE is user-friendly
with all switch settings on the rear panel and system-
friendly with its flexible control and small size.
With the built in electronic trigger shutter excellent
images can be captured of even fast moving objects.
Offering high picture quality and excellent sensitivity,
the XC-ST70/ST70CE is ideal for a number of uses
including industrial, microscopy, and machine vision
applications.
Compact camera adaptor
DC-700/700CE
• Compact, lightweight
• Two video outputs
• External sync IN/OUT
• Trigger input/WEN output
• New EIA standard 12 pin assignment
• Dimensions:
110(W) x 53(H) x 160(D) mm
CCD B/W VIDEO CAMERA MODULE
XC-ST70
XC-ST70CE
FEATURES
• 2/3" IT HAD CCD
• Small and light weight: 44(W) x 29 (H) x 57.5 (D) mm, 105 g
• High sensitivity: 0.3 lx (F1.4)
• High S/N ratio: 60 dB
• Electronic shutter function (1/100 to 1/10,000 s)
• Flexible trigger shutter functions
- simple trigger with internally generated VD and Write
Enable (WEN)
- exposure control with switches or trigger pulse width
• Readout on command (with VD input)
• 2:1 interlace/non-interlace
• Frame/field exposure
• Restart/Reset function
• Synchronization: internal/external (HD/VD, VS)
• High shock and vibration tolerance
ACCESSORIES
12 pin camera cable (CE standard)
CCXC-12P02N (2m)
CCXC-12P05N (5m)
CCXC-12P10N (10m)
CCXC-12P25N (25m)
