All about the
Use
of your
Important Safety Instructions ......................2
Features at a Glance ...................................4
Installation ................................................5
Door Removal Instructions ..........................7
Handle Installation .....................................9
Controls ...................................................12
www.frigidaire.com USA 1-800-944-9044
&
Care
Refrigerator
TA B L E O F C O N T E N T S
Storage Features ......................................15
Automatic Ice & Water Dispenser ..............17
Changing the Filter ...................................20
Normal Operating Sounds and Sights .........22
Care and Cleaning ....................................23
Before you Call .........................................28
Major Appliance Warranty .........................32
www.frigidaire.ca Canada 1-800-265-8352
Advertisement
Table of Contents
Related Manuals for Frigidaire FGHC2355PF
Summary of Contents for Frigidaire FGHC2355PF
-
Page 1: Table Of Contents
Changing the Filter ........20 Door Removal Instructions ......7 Normal Operating Sounds and Sights ..22 Handle Installation ........9 Care and Cleaning ........23 Connecting Water Supply ......10 Before you Call .........28 Controls ...........12 Major Appliance Warranty ......32 www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352... -
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Installation Checklist WARNING Doors Please read all instructions before using this refrigerator. Handles are secure and tight Door seals completely to cabinet on For your Safety all sides • DO NOT store or use gasoline, or other ... -
Page 3: Electrical Information
IMPORTANT SAFETY INSTRUCTIONS – even if they will sit for “just a few days”. If Avoid connecting refrigerator to a Ground you are getting rid of your old refrigerator or Fault Interrupter (GFI) circuit. Do not use an extension cord or adapter plug. freezer, please follow the instructions below to help prevent accidents. -
Page 4: Features At A Glance
Special Item Small Basket Rack Large Meat Keeper Glide Out and Cover Basket Can Rack Crisper Pan and Cover Fixed Door Bin Toe Grille IMPORTANT Features not included with your refrigerator can be purchased at www.frigidaire.com or by calling 1-800-944-9044. -
Page 5: Installation
INSTALLATION Toe Grille Installation and Removal This Use & Care Guide provides general operating instructions for your model. Use the To install toe grille refrigerator only as instructed in this Use & Care Guide. Before starting the refrigerator, 1 Open both doors. Slide left and right sides of follow these important first steps. -
Page 6: Door Opening
INSTALLATION Door Opening To level the doors using the adjustable lower hinge (some models): 1 Before leveling either door, remove set NOTE screw that locks door height into position. (The door cannot be adjusted without set he refrigerator doors are designed to shut screw removed). -
Page 7: Door Removal Instructions
DOOR REMOVAL INSTRUCTIONS 2 Open both doors and remove the toe grille Tools Necessary: (as explained in the Installation Instructions that came with your appliance). 3 Remove any food from the door shelves. 4 Close the doors. To remove the refrigerator top hinge cover: 1 Remove the three screws from each cover Phillips™... - Page 8 DOOR REMOVAL INSTRUCTIONS 2 Trace lightly around the hinge with a 3 Remove the two bottom hinge screws and pencil. This makes reinstallation easier. hinge if necessary. 3 Detach the water tube from the connector located below the freezer door. The Door connector releases when you press its outer sleeve inward.
-
Page 9: Handle Installation
HANDLE INSTALLATION Frigidaire Professional ® CAUTION Freezer Upper Refrigerator Upper End Cap End Cap Wear gloves and safety goggles and use extreme CAUTION when installing these handles. The rounded end of the handles may be sharp (some models). IMPORTANT To ensure proper installation of... -
Page 10: Connecting The Water Supply
6 ft. Stainless Steel Water Line) and for manufacturer will not be responsible for homes without an existing valve, Frigidaire any damage if plastic tubing is used for recommends its Smart Choice water line kit ®... - Page 11 CONNECTING THE WATER SUPPLY 5 With steel clamp and screw, secure water Plastic Water Tubing supply line (copper tubing only) to rear Steel to Ice Maker panel of refrigerator as shown. Clamp Fill Tube 6 Coil excess water supply line (copper tubing only), about 2½...
-
Page 12: Controls
CONTROLS User Interface (varies by model) Enlarged view of user interface display menu (varies by model) -
Page 13: Setting Cooling Temperatures
CONTROLS options air filter Used to enter and exit the Displays the current status of (∧ or ∨) options menu and make the air filter (Good, Order, or selections. Replace). To reset the filter status to “Good”, press and exit Toggles the options and run hold the “set” key for three modes. -
Page 14: Alarms
CONTROLS Alarms Sabbath Mode The Sabbath Mode is a feature that disables Power In the event of a power failure, portions of the refrigerator and its controls Failure the power fail alert will be in accordance with observance of the weekly illuminated. -
Page 15: Storage Features
STORAGE FEATURES The dairy compartment, which is warmer than the CAUTION general food storage section, is intended for short term storage of cheese, spreads, or butter. To avoid personal injury or property damage, Fresh Drawers with Humidity handle tempered glass shelves carefully. Control (some models) Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature... - Page 16 STORAGE FEATURES Chill Drawer (some models) Some models are equipped with a Chill Drawer. Chill Drawer temperatures can be adjusted by sliding the Chill Drawer Temperature Control in either direction. Use this pan for short term storage of bulk meat items. If meats are to be kept longer than one or two days, they should be frozen. The Chill Drawer is fixed and cannot be moved up or down. If fruits or vegetables are to be stored in the Chill Drawer, set the Chill Drawer Temperature Control to a warmer setting to prevent freezing.
-
Page 17: Automatic Ice & Water Dispenser
AUTOMATIC ICE & WATER DISPENSER Priming the Water Supply System Ice Production: What to Expect How Much Ice Will a Side Mounted Ice Your refrigerator’s water supply system includes Maker Produce in 24 Hours? several tubing lines, an advanced water filter, a distribution valve bank, and a reserve tank A side mounted ice maker will produce 4 to to ensure ample supply to the ice and water 4.5 pounds of ice every 24 hours, depending on... - Page 18 AUTOMATIC ICE & WATER DISPENSER Ice Maker/Dispenser Tips Turning the REAR MOUNTED Ice Maker On and Off • Ice cubes stored too long may develop an odd flavor. Empty the ice container as Ice production is controlled by the ice maker’s explained below. ON/OFF power switch. To gain access to the • Occasionally shake the ice container to ice maker, pull the ice cream shelf out.
-
Page 19: Cleaning The Ice Maker
AUTOMATIC ICE & WATER DISPENSER Cleaning the Ice Maker Clean the ice maker and ice bin at regular intervals, particularly before you take a vacation or move. To clean the ice maker: 1 Turn Off the ice maker. 2 Remove the ice bin by lifting up and out. 3 Empty and carefully clean the ice bin with mild detergent. -
Page 20: Changing The Filter
4 Slide the housing back into position. Air Filter Ordering Replacement Filters To order your replacement filters, please visit our online store at www.frigidaire.com/store, by calling toll-free at 877-808-4195, or by visiting the dealer where you purchased your refrigerator. Frigidaire recommends that you order extra filters when you first install your refrigerator, and that you replace your filters at least once every six months. -
Page 21: Water Filter
CHANGING THE FILTER More about your Advanced 7 After filling one glass of water, continue flushing the system for about four Water Filter minutes. The PureSource Ultra 8 Turn On the ice maker. and water filter system is tested 9 Press and hold the Water Filter button and certified to NSF/ANSI on the Ice & Water Dispenser control Standards 42 and 53 for the panel for three seconds. -
Page 22: Normal Operating Sounds And Sights
NORMAL OPERATING SOUNDS AND SIGHTS Understanding the Sounds you NOTE may Hear Your new, high-efficiency refrigerator may Energy efficient foam in your refrigerator is introduce unfamiliar sounds. These sounds not a sound insulator. normally indicate your refrigerator is operating correctly. Some surfaces on floors, walls, and kitchen cabinets may make these sounds more noticeable. NOTE Following is a list of major components in your refrigerator and the sounds they can cause:... -
Page 23: Care And Cleaning
CARE & CLEANING Protecting your investment Keeping your refrigerator clean maintains appearance and prevents odor build-up. Wipe up any spills immediately and clean the freezer and fresh food compartments at least twice a year. When cleaning, take the following precautions: • Never use CHLORIDE or cleaners with bleach to clean stainless steel. - Page 24 CARE & CLEANING Care and Cleaning Tips Part Cleaning Agents Tips and Precautions Interior • Soap and water • Use two tablespoons of baking soda in one quart & Door of warm water. • Baking soda and Liners water • Be sure to wring excess water out of sponge or cloth before cleaning around controls, light bulb or any electrical part.
- Page 25 CARE & CLEANING Ice Chute Extension Installing the Ice Chute (some models) Extension The ice chute extension is designed to better direct ice flow into containers. 1 Turn the refrigerator off using the button on the control panel (refer to the “Controls” section of this Manual). 2 Align the extension with the ice chute so that the snap clips are just inside the front edge of the chute.
- Page 26 Ordering Replacement LED Lights (select models) The fresh food compartments of your refrigerator Order new LEDs by calling 877-808-4195, may have LED lights. Always use Frigidaire parts online at www.frigidaire.com/store, or through for replacement. the dealer where you bought the refrigerator.
- Page 27 CARE & CLEANING Replacing light bulbs (select models) Both the freezer and fresh food compartments of your refrigerator include light bulbs that will need replacing from time to time. Some lights have covers that you will need to remove Water before replacing the bulbs.
-
Page 28: Before You Call
BEFORE YOU CALL 1-800-944-9044 (United States) Visit our web site at www.frigidaire.com 1-800-265-8352 (Canada) CONCERN CAUSE SOLUTION AUTOMATIC ICE MAKER Ice maker is • Ice maker is turned off. • Turn on ice maker. For the fresh food ice not making any maker, press and hold the “Ice Off”... - Page 29 BEFORE YOU CALL CONCERN CAUSE SOLUTION AUTOMATIC ICE MAKER (Continued) Freezer ice • Ice maker wire signal • Move any item or frozen ice cubes that maker will not arm is being held down may block the signal arm from being in the stop making by a package in the off or upward position.
- Page 30 BEFORE YOU CALL CONCERN CAUSE SOLUTION DISPENSER (Ice & Water) (Continued) Water has an • Water has not been • Draw and discard 10-12 glasses of water odd taste and/ dispensed for an to freshen the supply. or odor. extended period of time. • Unit not properly connected • Connect unit to cold water line that to cold water line.
- Page 31 DIGITAL TEMPERATURE DISPLAY Digital • Electronic control system • Call your Frigidaire service representative, temperature has detected a who can interpret any messages or displays are performance problem. number codes flashing on the digital flashing.
-
Page 32: Major Appliance Warranty
Obligations for service and parts under this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice. Canada 1.800.944.9044 1.800.265.8352 Frigidaire Electrolux Canada Corp. 10200 David Taylor Drive 5855 Terry Fox Way Charlotte, NC 28262 Mississauga, Ontario, Canada...
