SPECIFICATIONS

1.Gas Concrete Nailer (NC40G)
Dimensions
Length Height Width
Weight
Includes battery and fuel cell
Nail capacity
Cycle rate
Battery
Fuel Cell
2. Battery Charger (UC7SD)
Input power source
Charging time
Charging voltage
Charging current
Weight
NOTE: The charging time may vary according to temperature and power source voltage.

NAIL SELECTION

WARNING
Be sure to use only the genuine HITACHI nails for
the NC40G. The use of any other nails can result in
tool malfunction and/or nail breakdown, leading
to serious injuries.
Only nails shown in the Table below can be driven with
this Nailer.
Plastic collated strip nails Min. Max.
.250" .250"
(6.3 mm) (6.3 mm)
.102"
.102"
(2.6 mm)
(2.6 mm)
— 11 —
16-1/2" 13-7/8" 4-1/4"
(420 mm 352 mm 108 mm)
7.5 lbs. (3.4 kg)
8.2 lbs. (3.7 kg)
40 nails (4 strip)
Intermittent: 1 nail per second
Continuous: 1,000 nails per hour
EB714S (1.4 Ah)
Ni-Cd battery, 7.2 V
Type No. 728-980 ...... sold separately
Single phase: AC120V 60Hz
Approx. 60 min.
(At a temperature of 70°F (20°C))
DC 7.2 V
DC 1.6 A
2.4 lbs. (1.1 kg)
