Canon PIXMA MX372 Specifications

ENGLISH
Canon Inkjet Office All-In-One
Equipo multifunción para oficina Canon Inkjet

Specifications

General Specifications
Printing resolution (dpi)
4800* (horizontal) X 1200 (vertical)
* Ink droplets can be placed with a pitch of 1/4800 inch at minimum.
Interface
USB Port:
Hi-Speed USB *1
*1 A computer that complies with Hi-Speed USB standard is required.
Since the Hi-Speed USB interface is fully upwardly compatible with
USB 1.1, it can be used at USB 1.1.
Print width
8 inches/203.2 mm (for Borderless Printing: 8.5 inches/216 mm)
Operating environment
Temperature: 5 to 35 °C (41 to 95 °F)
Humidity: 10 to 90 % RH (no condensation)
Storage environment
Temperature: 0 to 40 °C (32 to 104 °F)
Humidity: 5 to 95 % RH (no condensation)
Power supply
AC 100-240 V, 50/60 Hz
Power consumption
Printing (Copy): Approx. 14 W
Standby (minimum): Approx. 1.6 W *1*2
OFF: Approx. 0.4 W *1
*1 USB connection to PC
*2 The wait time for standby cannot be changed.
External dimensions
Approx. 18.1 (W) X 15.2 (D) X 7.9 (H) inches
Approx. 458 (W) X 385 (D) X 200 (H) mm
* With the Front Cover retracted.
Weight
Approx. 8.4 kg (Approx. 18.5 lb)
* With the FINE Cartridges installed.
Canon FINE Cartridge
Total 1792 nozzles (BK 640 nozzles, C/M/Y each 384 nozzles)
ADF capacity
A4 or Letter size: max. 30 sheets (20 lb/75 gsm paper), up to 0.16
inches/4 mm in height
Legal size: max. 5 sheets (20 lb/75 gsm paper), up to 0.04 inches/1
mm in height
Other sizes: 1 sheet
QT5-4705-V01
ESPAÑOL
MX370
Fax Specifications
Applicable line
Public Switched Telephone Network (PSTN)
Communication mode
Super G3, G3
Data compressing system
Black: MH, MR, MMR
Color: JPEG
Modem speed
max. 33.6 kbps
(Automatic fallback)
Transmission speed
Black: Approx. 3 seconds/page at 33.6 kbps
(Based on ITU-T No.1 chart for US specifications and Canon FAX
Standard chart No.1 for others, both in standard mode.)
Color: Approx. 1 minute/page at 33.6 kbps
(Based on Canon COLOR FAX TEST SHEET.)
Gradation
Black: 256 levels
Color: 24 bit Full Color (RGB each 8 bit)
Density adjustment
3 levels
Memory
Transmission/reception: approx. 50 pages
(Based on ITU-T No.1 chart for US specifications and Canon FAX
Standard chart No.1 for others, both in standard mode.)
Fax resolution
Black Standard: 203 pels/inch X 98 lines/inch (8 pels/mm X 3.85
lines/mm)
Black Fine, Photo: 203 pels/inch X 196 lines/inch (8 pels/mm X 7.70
lines/mm)
Black Extra Fine: 300 X 300 dpi
Color: 200 X 200 dpi
Dialing
Automatic dialing
Coded speed dial (max. 20 destinations)
Group dial (max. 19 destinations)
Regular dialing (with Numeric buttons)
Automatic redialing
Manual redialing (max. 10 destinations)
Others
Activity report (after every 20 transactions)
Sequential broadcasting (max. 21 destinations)
Rejected numbers (max. 10 destinations)
XXXXXXXX
Copy Specifications
Multiple copy
max. 99 pages
series
Intensity adjustment
9 positions, Auto intensity (AE copy)
Reduction/Enlargement
25 % - 400 % (1 % unit)
K10374
Scan Specifications
Scanner driver
TWAIN/WIA (for Windows 7/Windows Vista/Windows XP)
Maximum scanning size
A4/Letter, 8.5" X 11.7"/216 X 297 mm (Platen Glass), 8.5" X 14.0"/216
X 356 mm (ADF)
Scanning resolution
Optical resolution (horizontal X vertical) max: 1200 X 2400 dpi *1
Interpolated resolution max: 19200 X 19200 dpi *2
*1 Optical Resolution represents the maximum sampling rate based
on ISO 14473.
*2 Increasing the scanning resolution will limit the maximum possible
scanning area.
Gradation (Input/Output)
Gray: 16 bit/8 bit
Color: 48 bit/24 bit (RGB each 16 bit/8 bit)
©CANON INC.2012
CANON U.S.A. INC.
One Canon Plaza, Lake Success, NY 11042 U.S.A.
www.usa.canon.com/
Minimum System Requirements
Conform to the operating system's requirements when higher than
those given here.
Operating System/Processor/RAM
Windows 7, Windows 7 SP1 Mac OS X Lion 10.7
1 GHz or faster 32-bit (x86) or 64- Intel Core 2 Duo, Core i3, Core i5,
bit (x64) processor Core i7, or Xeon processor
1 GB (32-bit)/2 GB (64-bit) 2 GB
Windows Vista, Vista SP1, Vista Mac OS X 10.6
SP2 Intel processor
1 GHz processor 1 GB
512 MB
Mac OS X 10.5.8
Windows XP SP2, SP3 32-bit only Intel processor, PowerPC G5,
300 MHz processor PowerPC G4 (867 MHz or faster)
128 MB 512 MB
Browser
Internet Explorer 6 or later Safari 3 or later
Hard Disk Space
1.5 GB 1.5 GB
Note: For bundled software Note: For bundled software
installation. installation.
The necessary amount of hard disk The necessary amount of hard
space may be changed without disk space may be changed
notice. without notice.
CD-ROM Drive
Required Required
Display
SVGA 800 X 600 XGA 1024 X 768
• Windows: Operation can only be guaranteed on a computer with
Windows 7, Windows Vista or Windows XP pre-installed.
• Windows: Uninstall software bundled with the Canon inkjet printer
before upgrading from Windows Vista to Windows 7, then install the
bundled software again.
• Windows: Some functions may not be available with Windows Media
Center.
• Windows: Internet Explorer 7, 8 or 9 is required to install Easy-
WebPrint EX.
Microsoft .NET Framework 4 Client Profile must be installed to use
Easy-WebPrint EX in Internet Explorer 9.
• Macintosh: Hard Disk must be formatted as Mac OS Extended
(Journaled) or Mac OS Extended.
• Macintosh: After upgrading from Mac OS X 10.6 to Mac OS X Lion
10.7, install software bundled with the Canon inkjet printer.
Specifications are subject to change without notice.
About Consumables
Consumables (ink tanks / FINE Cartridges) are available for 5 years
after production of the machine has stopped.
PRINTED IN XXXXXXXX
