Specifications - JBL SOUNDPOINT SP5II Owner's Manual

SPECIFICATIONS

SP5II SP6II
Frequency Response Frequency Response
45Hz– 20kHz (–10dB) 38Hz – 20kHz (–10dB)
Recommended Maximum Recommended Maximum
Amplifier Power Amplifier Power
†
60 watts 80 watts
Impedance Impedance
8 ohms nominal 8 ohms nominal
Sensitivity Sensitivity
87dB (2.83V/1m) 88dB (2.83V/1m)
Crossover Frequency Crossover Frequency
3,000Hz 2,800Hz
Woofer Woofer
5-1/4" titanium-laminate 6-1/2" titanium-laminate
cone w/rubber surround cone w/rubber surround
Tweeter Tweeter
1"titanium-laminate 1"titanium-laminate
dome, w/Elliptical Oblate dome, w/Elliptical Oblate
Spheroidal ™ waveguide Spheroidal
and swivel mount and swivel mount
Plate Size (W x H) Plate Size (W x H)
7-1/2" x 10" (191mm x 254mm) 8-1/2" x 11" (216mm x 279mm)
Mounting Cutout Size (W x H) Mounting Cutout Size (W x H)
6-1/8" x 8-11/16" (156mm x 221mm) 7-1/8" x 9-11/16" (181mm x 246mm) 7-7/8" (200mm)
Mounting Depth Mounting Depth
3-3/4" (95mm) 3-7/8" (98mm)
Weight per Speaker Weight per Speaker
4 lb (1.8kg) 5 lb (2.3kg)
All features and specifications are subject to
change without notice.
† The maximum recommended amplifier power
rating will ensure proper system headroom to
allow for occasional peaks. We do not recom-
mend sustained operation at these maximum
power levels.
Dolby is a registered trademark of Dolby
Laboratories.
DTS is a registered trademark of DTS, Inc.
OWNER'S GUIDE
P R O D U C T L I N E :
SOUNDPOINT
M O D E L S :
SP5II, SP6II, SP6CII, SP6CSII, SP8II, SP8CII
Combine the superior performance of traditional
DESIGN GOAL:
JBL loudspeakers with the convenience of in-wall installation.
Titanium-laminate-dome with swivel mount
TWEETER TYPE:
Titanium-laminate cone with rubber surround
WOOFER TYPE:
CROSSOVER NETWORK:
2
PROFESSIONAL REFERENCE:
SP6CII
Frequency Response
40Hz– 20kHz (–10dB)
Recommended Maximum Recommended Maximum
Amplifier Power
† †
80 watts
Impedance
8 ohms nominal
Sensitivity
88dB (2.83V/1m)
Crossover Frequency
2,600Hz
Woofer
6-1/2" titanium-laminate
cone w/rubber surround
Tweeter
1"
titanium-laminate
™ waveguide dome,
w/swivel mount
Plate Size (Diameter)
9-3/16" (233mm)
Mounting Cutout Size (Dia.) Mounting Cutout Size (Dia.)
Mounting Depth
4-1/4" (108mm)
Weight per Speaker
4.5 lb (2.0kg)
® SERIES
Straight-Line Signal Path ™ (SSP)
Studio Monitor
SP6CSII
Frequency Response
40Hz – 20kHz (–10dB)
Amplifier Power
†
100 watts total (50WPC)
Impedance
8 ohms nominal per input
Sensitivity
88dB (2.83V/1m), both channels driven 89dB (2.83V/1m)
Crossover Frequency
2,600Hz
Woofer
6-1/2" titanium-laminate
cone w/rubber surround
Tweeters
Dual 3/4"
titanium-laminate
domes,
w/swivel mounts
Plate Size (Diameter)
9-3/16" (233mm)
7-7/8" (200mm)
Mounting Depth
4-1/4" (108mm)
Weight per Speaker
4 lb (1.8kg)
Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this
owner's manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Harman Consumer Group International
PRO SOUND
COMES HOME
JBL, Incorporated
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
516.255.4JBL (4525) www.jbl.com
For new-construction applications, be sure
NOTE:
to purchase the correct rough-in frame kit.
©2006 Harman International Industries, Incorporated. All rights reserved.
JBL, Harman International and SoundPoint are registered trademarks of
Harman International Industries, Incorporated.
Part Nos. 406-000-05268-E, 170-0091
7/06
SP8II SP8CII
Frequency Response Frequency Response
30Hz – 20kHz (–10dB) 32Hz – 20kHz (–10dB)
Recommended Maximum Recommended Maximum
Amplifier Power Amplifier Power
†
100 watts 100 watts
Impedance Impedance
8 ohms nominal 8 ohms nominal
Sensitivity Sensitivity
89dB (2.83V/1m)
Crossover Frequency Crossover Frequency
2,400Hz 2,400Hz
Woofer Woofer
8" titanium-laminate 8" titanium-laminate
cone w/rubber surround cone w/rubber surround
Tweeter Tweeter
1"titanium-laminate 1"titanium-
dome, w/Elliptical Oblate laminate
Spheroidal ™ waveguide dome,
and swivel mount w/swivel mount
Plate Size (W x H) Plate Size (Diameter)
10-1/8" x 13-1/8" (257mm x 333mm) 10-7/8" (275mm)
Mounting Cutout Size (W x H) Mounting Cutout Size (Dia.)
8-7/8" x 11-13/16" (225mm x 300mm) 9-1/2" (240mm)
Mounting Depth Mounting Depth
4" (102mm) 4-1/4" (108mm)
Weight per Speaker Weight per Speaker
7.8 lb (3.5kg) 5.6 lb (2.5kg)
Laurent Rault
Château du Loir, France 7/06
™
†
