Specifications:

System:
Maximum Recommended
Amplifier Power:
Nominal Impedance:
Crossover Frequency:
System Sensitivity:

Low Frequency Transducer:

Model:
Nominal Diameter:
Voice Coil Diameter:
Sensitivity:

High Frequency Driver/Horn:

Models: 2426H Driver and H2600 Horn
Voice Coil Diameter: 45mm (1.75in) Edgewound Aluminum Ribbon
Magnetic Assembly Weight: 4.5kg (10lb)
Flux Density: 1.8T (18,000 gauss)
Sensitivity (on driver axis): 108dB (1 watt @ 1m)
General:
Dimensions:
Net Weight:
Shipping Weight:
JBL Consumer Products, Inc.
80 Crossways Park West
Woodbury, NY 11797
8500 Balboa Blvd.
Northridge, CA 91329
1-800-336-4JBL
A Harman International Company
S2600/S3100 LOUDSPEAKER SYSTEMS
S2600
400 watts
6 ohms
950Hz
92dB
(2.83V @ 1 m)
ME120 HS
300mm (12in)
75mm (3in)
92dB
(2.83V @ 1 m)
984mm H x 559mm W
x 406mm D
(38.75" x 22" x 16")
52.3kg
(115lb)
59kg
(130lb)
S3100
400 watts
6 ohms
750Hz
94dB
(2.83V @ 1 m)
ME150 HS
380mm (15in)
100mm (4in)
95dB
(2.83V @ 1 m)
1111mm H x 559mm W
x 406mm D
(43.75" x 22" x 16")
56.8kg
(125lb)
63.6kg
(140lb)
Printed in USA on recycled paper 10/94
Part No. OMS2600/S3100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S3100 and is the answer not in the manual?

Questions and answers

Related Manuals for JBL S3100

Summary of Contents for JBL S3100

  • Page 1 S2600/S3100 LOUDSPEAKER SYSTEMS Specifications: System: S2600 S3100 Maximum Recommended Amplifier Power: 400 watts 400 watts Nominal Impedance: 6 ohms 6 ohms Crossover Frequency: 950Hz 750Hz System Sensitivity: 92dB 94dB (2.83V @ 1 m) (2.83V @ 1 m) Low Frequency Transducer:...
  • Page 2 S2600, S3100 LOUDSPEAKER SYSTEMS OWNER’S MANUAL S 2 6 0 0 S 3 1 0 0...
  • Page 3 S 3 1 0 0 S 2 6 0 0...
  • Page 4 In the condition we have stereophonic imaging, and the described here, place the loud- S2600 and S3100 systems, like the speakers so that their baffles are Project Everest DD55000 system parallel to the wall behind them.
  • Page 5 3 meters, set a in the range of 5 to 10 degrees. THEORY OF OPERATION: The uniform imaging properties ELECTRICAL CONNECTIONS: of the S2600 and S3100 systems The models S2600 and S3100 are based on the asymmetrical hori- are can be operated by a normal...
  • Page 6 Both of these cues favor localiza- tion at the nearer loudspeaker, and 0 dB 0 dB the soundstage is skewed accord- ingly. With the S2600 and S3100 sys- tems, an off-axis listener will be 50° 50° located along a zone of higher sen- 40°...
  • Page 7 TYPICAL SYSTEM PERFORMANCE: Figure 5 shows the on-axis sine Figure 6 shows second and wave response of the S2600 sys- third harmonic distortion for the tem taken in a 2π environment S2600 system at a level of 96dB (adjacent to one wall), with contri- SPL measured at a distance of butions from low and high frequen- 1 meter.
  • Page 8 S2600 and tions unless otherwise stated. S3100 systems are designed and built very much in the JBL tradition of fine workmanship and the use of the best materials. Both LF trans- ducers are new designs that incor- porate Aquaplas®...
