JBL SP6II SoundPoint Series Technical Manual

Technical Manual
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Grille
• Low-Frequency Transducer
DC Resistance
• High-Frequency Transducer
DC Resistance
• Crossover Network
PACKAGING
4
3
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
8
80 watts*
38Hz – 20kHz (–10dB)
88dB (2.83V @ 1 meter)
2,800Hz
590-0263
6-1/2" (165mm) titanium-lami-
nate cone w/rubber surround
(590-0348)
5.9 ohms
1" (25mm) titanium-laminate
dome, w/swivel mount
(590-0278)
7.9 ohms ±10%
590-0281
Legend on Page 2
12
2
5
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Plate Size (W x H)
• Mounting Cutout
Size (W x H)
• Mounting Depth
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
6.0V Input 35Hz to 20kHz
5.0V Input 35Hz to 3kHz
2.83V Input 2kHz to 20kHz
8-1/2" x 11" (216mm x 297mm)
7-1/8" x 9-11/16"
(181mm x 246mm)
3-7/8" (98mm)
10 lb (4.5kg) Sold in pairs
6/07
