24g series flatbottom gas fryers
Hide thumbs Also See for FLAT BOTTOM 1824/2424G:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operation & Installation Manual
Models SCF/SCFC 1824G, 2424G and 1824/2424G
Systems with Built-In Filtration
NON-CE
&
Frymaster Dean, a member of the Commercial Food Equipment Service Association,
recommends using CFESA Certified Technicians.
24-Hour Service Hotline
PRINTED IN THE USA
DEC 2008
1-800-551-8633
*8196031*
service@frymaster.com
www.frymaster.com
