Rev Counter; Fuel Gauge And Reserve Warning Light; Engine Coolant Temperature Gauge And Maximum Temperature Warning Light - Alfa Romeo 156 Owner's Manual

REV COUNTER

The rev. counter shows engine rpm. The
needle pointed to the danger area (red) in-
dicates excessive high engine speed. Do not
drive for long periods with the needle in this
area.
WARNING The electronic injection con-
trol system gradually shuts off the flow of
fuel when the engine is "over-revving" re-
sulting in a gradual loss of engine power.
The rev counter may, when the engine is
idling, indicate gradual or sudden increase
of engine revs as the case may be; such be-
haviour is normal and must not be inter-
preted as a faulty condition as it occurs dur-
ing normal operation, for instance when
climate control or electric fan are switched
on. In particular, slow revs variation helps
keep the battery charged.
62
FUEL GAUGE AND RESERVE
WARNING LIGHT
This shows the amount of fuel left in the
fuel tank.
This warning light ç comes on to indicate
that approximately 7 litres of fuel are left in
the tank.
WARNING Under certain conditions
(heavy slopes, for instance), the reading on
the gauge may differ from the actual
amount of fuel in the tank and changes in
level may be indicated late.
This condition falls within the operation log-
ics of the electronic control circuit to avoid
highly unstable readings due to swaying of
the fuel when travelling.
WARNING Refuelling shall always be
performed with engine off and ignition key
to STOP. If the engine is off but the key
is to MAR, a wrong fuel level could tem-
porarily be indicated. This is due to the in-
ternal system control logic and cannot be
considered as a system malfunctioning.
ENGINE COOLANT
TEMPERATURE GAUGE AND
MAXIMUM TEMPERATURE
WARNING LIGHT
This shows the temperature of the engine
coolant fluid and begins when the fluid tem-
perature exceeds approx. 50°C.
The pointer should normally be towards
the middle of the scale. If the pointer
reaches the higher temperature values of
the scale (red area), the request for vehi-
cle performance should be decreased.
The illumination of the warning light ç
(together with the message shown by the
Infocenter display) indicates an excessive
temperature of the engine cooling fluid. In
this case, stop the car and contact Alfa
Romeo Authorized Services.
WARNING The temperature of the en-
gine coolant may rise towards the maximum
values (red) when the vehicle is driven at
low speeds, especially when the ambient air
temperature is high. In this case, the vehi-
cle should be stopped and the engine
switched off for a few minutes after which
the journey can be resumed, preferably at
a higher speed.
