Daewoo KOR-836T Operating Instructions Manual

Daewoo KOR-836T Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

MICROWAVE OVEN

OPERATING
INSTRUCTIONS
KOR-836T
Stage
Defrost
1
2
Quant. Weight
Lock
Auto
Watt
cook
Defrost
A
Power
Autocook
1. Beverage
2. Soup
3. Casserole
4. vegetable I
5. vegetable II
6. Fish Fillets
More
Less
Clock
Before operating this oven, please read
these instructions completely.
Time
g
1 min plus
Stop/Clear

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOR-836T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo KOR-836T

Summary of Contents for Daewoo KOR-836T

  • Page 1: Microwave Oven

    MICROWAVE OVEN KOR-836T Stage Defrost Quant. Weight Time OPERATING Lock Auto Watt cook Defrost INSTRUCTIONS Power 1 min plus Autocook 1. Beverage 2. Soup 3. Casserole 4. vegetable I 5. vegetable II 6. Fish Fillets Stop/Clear More Less Clock Before operating this oven, please read...

  • Page 2: Table Of Contents

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door, or allow soil or cleaner residue to accumlate on sealing surfaces.

  • Page 3: Installation And Earthing Instructions

    EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric currrent. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be inserted into an outlet that is properly installed and earthed.

  • Page 4: Important Safety Instructons

    IMPORTANT SAFETY INSTRUCTONS When using electrical apliances, basic safety precautions General Use should be followed, including the following: Listed below are, as with all appliances, certain rules to WARNING-To reduce the risk of burns, electric shock, fire, follow and safeguards to assure top performance from injury to persons or exposure to excessive microwave this oven: energy:...

  • Page 5: Which Utensil Can Be Used In The Oven

    TO AVOID EXPLOSION AND SUDDEN BOILIING 1. Eggs Never cook eggs in their shells. Steam will build up inside the shell during cooking and the egg will explode. WARNING If you want to cook or reheat eggs which have not been When heating liquids, e.g.

  • Page 6: Control Panel

    CONTROL PANEL When blinking, the oven is in When blinking, the oven is operating quantity input mode. in WEIGHT DEFROST. When blinking, the oven is operating When blinking, the oven is in STAGE 2. operating in TIME DEFROST. When blinking, the oven is operating in STAGE 1.

  • Page 7: Accessories And Keep The Oven Clean

    ACCESSORIES This oven comes equipped with several accessories. § Earth instructions They can be used in various ways to facilitate cooking. Be sure to follow specific directions for their use when WARNING - To prevention electrical shock, this given in charts or recipes in the cookbook. appliance should be earthed.

  • Page 8: How To Set The Oven Controls

    HOW TO SET THE OVEN CONTROLS Tips: ¡ Be sure to read the cookbook¡fl s introduction before operating the oven. ¡ Also remember to read this operating instruction for proper safety information and instruction before using the oven. ¡ See the cookbook for specific recipes. ¡...
  • Page 9 4. Press CLOCK button. The display will show present time, and the colon starts blinking. This digital clock allows you to set to “10:10” TIME DEFROST SETTING THE CONTROL The TIME DEFROST indicator light will 1. Press DEFROST button twice. TIME light up.

  • Page 10: Cooking In One Stage

    SETTING THE CONTROL 1. Press DEFROST button once The WEIGHT DEFROST indicator light will come on. WEIGHT The g indicator light will start blinking. 2. Turn the DIAL KNOB for the desired The 1000 will show in the display WEIGHT defrosting weight This display represent 1000g.
  • Page 11 2. Turn the DIAL KNOB for the desired 10:00 will show in the display. cooking time. STAGE For example: 10minutes NOTE: Time can be set up to 99 minutes. 3. Press START button The STAGE1 indicator light will starts STAGE blinking to show the oven is in the MICROWAVE mode 4.
  • Page 12 4. Turn the DIAL KNOB for the desired 4:20 will show in the display. STAGE cooking time. For example: 4 min. 20 sec. When you press START button, both STAGE1 & 2 indicator lights come on, 5. Press START button. STAGE1 indicator light blinking to show you that the oven is cooking in the first of two cook stages.

  • Page 13: Auto Cook

    4. Turn the DIAL KNOB for the desired STAGE cooking time. Note: Time can be set up to 99 For example: 5 min. 30 sec. minutes. The STAGE2 indicator light will light. 5. Press POWER button. STAGE "500" is displayed and WATT indicator Select POWER LEVEL.
  • Page 14 2. Select the desired cooking. ¡ AC-2¡– will show in the display. Quantity For example: SOUP Press AUTO COOK button twice. AUTO COOK 3. If you want to select other menu, press AUTO COOK button until display your desired cooking menu. 4.
  • Page 15 NOTE: ¡ AUTO COOK menu and quantity. MENU NO QUANTITY NO 1 CUP BEVERAGE 2 CUPS 3 CUPS 4 CUPS 200g SOUP 400g CASSEROLE 600g 800g BEVERAGE ¥ 680 g BEVERAGE ¥– 450 g FISH FILLET 450 g SPEEDY COOK 1.

  • Page 16: To Stop The Oven While It Is Operating

    STAGE COMBINATIONS This oven has the ability to be programmed to do up to three consecutive functions. These combinations are given below and either the complete progrm or part of it can be used. STAGE COOKING WEIGHT/TIME DEFROST STAGE 1 STAGE 2 ƒN When you set stage mode, indicator is lighted only setting.

  • Page 17: General Guidelines

    GENERAL GUIDELINES Since microwave cooking to some extent is different from Several foods are tightly covered by a skin or membrane. traditional cooking, the following general guidelines should be These foods should be picked with a fork or cocktail stick to considered whenever you use your microwave oven: relieve the pressure and to prevent bursting, as steam builds up within them during cooking.

  • Page 18: Before Calling For Service

    BEFORE CALLING FOR SERVICE You can often correct operating problems yourself. If Note: your microwave oven fails to work properly, locate the It is quite normal for steam to be emitted around the door operating problem in the chart below and try the during the cooking cycle.

  • Page 19: Questions And Answers

    QUESTIONS AND ANSWERS Q: I accidentally ran my microwave oven without any Q: The oven only operates when the door is closed. food in it. is it damaged? A: The operation of the fan motor is at the same time as the A:We do not recommend to operating the microwave oven oven is operating.
