- Page 1 MICROWAVE OVEN KOR8A9RW KOR8A9RC KOR8A9RT KOR8A9RR KOR8A9RB OWNER'S MANUAL Before operating this oven, please read these instructions completely. DESUK_KOR819RWWUB015UW00외(영).indd 2 16. 1. 4. 오후 3:49...
-
Page 2: Precautions To Avoid Possible Exposure To Excessive Microwave Energy
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. - Page 3 How to unbox / install / maintain microwave - http://www.youtube.com/watch?v=UdbpMO7VG0w Customer Helpline Number : 0118 925 2525 Spare Parts : 0844 557 0270 or www.4daewoo.co.uk / DAEWOO ELECTRONICS Web Site www.daewooelectronics.co.uk DESUK_KOR-6LBR5S(영).indd 3 15. 5. 22. 오후 3:17...
-
Page 4: Table Of Contents
TABLE OF CONTENTS • PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ..1 • IMPORTANT SAFETY INSTRUCTIONS ..................3 • EARTHING INSTRUCTIONS .......................5 • INSTALLATION ..........................5 • SPECIFICATIONS .........................6 • FEATURES DIAGRAM ......................7~8 • OPERATION PROCEDURE ......................9 • CONTROLS ..........................10 SETTING THE CLOCK .......................10 WEIGHT DEFROSTING ......................10 TIME DEFROSTING ........................11... -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 1. - Page 6 13. The contents of feeding bottles and baby removed from the microwave oven is not food jars shall be stirred or shaken and the always present. THIS COULD RESULT IN temperature checked before consumption, VERY HOT LIQUIDS SUDDENLY in order to avoid burns. BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO 14.
-
Page 7: Earthing Instructions
EARTHING INSTRUCTIONS IMPORTANT This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of The wires in this mains lead fitted to this appliance electric shock by providing an escape wire for the are colored in accordance with the following code. -
Page 8: Specifications
SPECIFICATIONS POWER SUPPLY 240V AC 50 Hz SINGLE PHASE WITH EARTHING POWER CONSUMPTION 1200 W MICROWAVE OUTPUT POWER 800 W FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 465 X 280 X 358 mm CAVITY DIMENSIONS (W X H X D) 298 X 230 X 330 mm NET WEIGHT APPROX. -
Page 9: Features Diagram
FEATURES DIAGRAM 1 Door latch-When the door is closed it will 6 Control panel automatically shut off. If the door is opened while the oven is operating, the magnetron will 7 Glass cooking tray-Made of special heat automatically shut off. resistant glass. - Page 10 FEATURES DIAGRAM ( continued ) ③ ② ④ Clock ⑤ ① ⑥ ⑦ ⑧ ① Display - Cooking time, Power level, ⑥ Dial knob - Used to set time and weight. indicators and present time are displayed. ⑦ Stop/Clear - Used to stop the oven operation ②...
-
Page 11: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a 240V 50Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 12: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever turns off, the display shows “ :0” when the power comes back on. 1. -
Page 13: Time Defrosting
TIME DEFROSTING When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off. 1. Press Defrost button. The DEF. indicator & “0” appear and the g Defrost indicator starts blinking. -
Page 14: Cooking In One Stage
COOKING IN ONE STAGE 1. Press Power button. The M/W indicator appears and the display Power (Select the desired power will show what you selected. level.) This example shows power level 6. NOTE: If step 1 is omitted, the oven will cook at full power. -
Page 15: Easy Cook
EASY COOK EASY COOK allows you to reheat for 30 seconds at 100% (full power) by simply pressing the Easy cook button. By repeatedly pressing the Easy cook button, you can also extend reheating time to 5 minutes by 30 seconds. -
Page 16: Child Safety Lock
CHILD SAFETY LOCK SAFETY LOCK lock prevents unwanted oven operation such as by small children. To set, press and hold Stop/Clear button for 3 seconds, Lock indicator appears and a beep sounds. To cancel, press and hold Stop/Clear button for 3 seconds, Lock indicator disappears and a beep sounds. TO STOP THE OVEN WHILE THE OVEN IS OPERATING 1. -
Page 17: Care Of Your Microwave Oven
CARE OF YOUR MICROWAVE OVEN The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. It is occasionally necessary to remove the Turn the oven off before cleaning. -
Page 18: Questions And Answers
QUESTIONS AND ANSWERS * Q : I accidentally ran my microwave oven * Q : What does "standing time" mean? without any food in it. Is it damaged? A : “Standing time” means that food should be A : Running the oven empty for a short time will removed from the oven and covered for not damage the oven. -
Page 19: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn't work : * Sparking in the cavity; 1. Check that the power cord is securely plugged 1. Check utensils. Metal containers or dishes with metal trim should not be used. -
Page 20: Cooking Instructions
COOKING INSTRUCTIONS Utensil Guide Only use utensils that are suitable for use in microwave ovens. To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked microwave-safe, you do not need to worry. -
Page 21: Use Your Microwave Oven Safely
USE YOUR MICROWAVE OVEN SAFELY General Use Do not operate the oven if door seals or sealing Do not attempt to defeat or tamper with safety surfaces are damaged; or if door is bent; or if hinges interlocks. are loose or broken. Do not place any object between the oven front Do not operate the oven empty. -
Page 22: Microwaving Principles
MICROWAVING PRINCIPLES Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade sources. Manmade sources include radar, radio, television, telecommunication links and mobile phones. -
Page 23: Cooking Techniques
COOKING TECHNIQUES STANDING TIME STARTING TEMPERATURE Dense foods e.g. meat, jacket potatoes and The colder the food, the longer it takes to heat up. cakes, require standing time(inside or outside of Food from a fridge takes longer to reheat than the oven) after cooking, to allow heat to finish food at room temperature. -
Page 24: Defrosting Guide
DEFROSTING GUIDE ▶ Do not defrost covered meat. Covering might allow ▶ When defrosted, food should be cool, but softened in cooking to take place. Always remove outer wrap and all areas. If still slightly icy, return to microwave oven tray. -
Page 25: Cooking & Reheating Chart
COOKING & REHEATING CHART Cooking chart Power Cooking Time Item Special Instruction Level Per lb./450g MEAT Beef joint -Rare P-80 6-8 min. - Chilled meat and poultry should be removed from the refrigerator at least 30 minutes before -Medium P-80 7-9 min. - Page 26 Reheating chart • Baby food particularly needs to be checked carefully before serving to prevent burns. • When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully. • If you freeze foods which were bought from the fresh or chilled counters, remember that they should be thoroughly thawed before following the heating instructions on the packed.
-
Page 27: Vegetable Chart
VEGETABLE CHART Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless another water quantity is recommended - see table. Cook covered for the minimum time - see table. Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter after cooking. -
Page 28: Recipes
RECIPES TOMATO & ORANGE SOUP 1 oz.(25g) butter 1. Melt the in a large bowl on P-HI for 1 minute. 1 medium onion, chopped 2. Add the onion, carrot and potato and cook on P-HI 1 large carrot & 1 large potato, chopped for 4 minutes. - Page 29 BLUE CHEESE & CHIVE JACKETS 2 baking potatoes, 1. Prick each potato in several places. Cook on P-HI (approx.9 oz.(250g) each) for 7-9 minutes. Halve and scoop the flesh into a 2 oz.(50g) butter bowl, add the butter, cheese, chives, mushrooms, 4 oz.(100g) blue cheese, chopped salt and pepper, mix thoroughly.
- Page 30 SCRAMBLED EGG oz.(15g) butter 1. Melt the butter in a bowl on P-HI for 1 minute. 2 eggs 2. Add the eggs, milk and seasoning and mix well. 2 tbsp(30ml) milk 3. Cook on P-HI for 4 minutes, stirring every 30 salt &...
