Summary of Contents for Omega OS1592
- Page 1 User’ s Guide MADE IN Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info OS1592 Infrared Fiber Optic Thermometer/Transmitter...
- Page 2 Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
- Page 3 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
-
Page 4: Table Of Contents
Table of OS1592 Infrared Fiber Optic Thermometer/Transmitter Contents TABLE OF CONTENTS SECTION ..............PAGE Section 1 Introduction ................ 1 Section 2 Installation ................1 2.1 Unpacking ................1 2.2 Electrical Connection............3 Section 3 Operation ................4 3.1 Changing the Temperature from °F or °C (or vice versa) ... 5 3.2 Turning on the Display Backlight ........ - Page 5 7 Optical Lens Assembly (L1) .076" @ 6" FOV ........7 8 Ceramic Tip Assembly (L2) .............. 7 9 Polymer Bolt Assembly (L3) with 90° Angle Air Purge Fitting ..8 10 Optical Head, Mounting Bracket, OS1592-MB ......8 11 Air Purge Collar, OS1592-AP ............8...
-
Page 6: Section 1 Introduction
OS1592 Infrared Fiber Optic Thermometer/Transmitter INTRODUCTION The new OS1592 series Infrared Fiber Optic Thermometer/Transmitter provides non-contact temperature measurement for industrial applications. The unit measures temperature starting at 260°C (500°F) and up to 2482°C (4500°F). It provides dual analog outputs (4-20 mA, 0-5 VDC, 0-10 VDC, 1 mV/Deg, J &... - Page 7 OS1592 Infrared Fiber Optic Thermometer/Transmitter The following describes the ordering information: To Order ( Specify Model Number ) Model No. Temperature Range Optical Assy (Spot Size) Cable Length OS1592-L1-R1-1-* 260/538°C (500 to 1000°F) Lens Probe 6.3 mm (0.25") @ 20.3 cm (8") 1.52 m (5')
-
Page 8: Electrical Connection
® THERMOMETER MODE °F ALARM °F–°C OS1590 SERIES CURRENT TEMPERATURE 4 POSITION MEMBRANE KEYPAD MODEL & S/N Figure 1 - OS1592 Main Unit RELAY/NO RELAY RELAY/NC CONTACTS RELAY/COM – 4/20mA ANALOG 1mV/Deg OUTPUTS 0/5VDC, 0/10VDC V/TC J & K T/C –... -
Page 9: Section 3 Operation
OS1592 Infrared Fiber Optic Thermometer/Transmitter OPERATION Table 1 shows all the display modes of the model OS1592, as well as all the functions of the membrane keypad. Fig 3 shows the Visual Functional flow chart of the display. DISPLAY Display shows:... -
Page 10: Changing The Temperature From °F Or °C (Or Vice Versa)
OS1592 Infrared Fiber Optic Thermometer/Transmitter NOTE: The Emissivity setting as well as the temperature Engineering unit (°F or °C) are stored in the non-volatile memory. Removing the main power will not erase or change these settings. 3.1 - Changing the Temperature from °F to °C (or vice versa) Press the key to go to either the MAX , MIN, or DIF display mode. -
Page 11: Resetting Temperature Values
OS1592 Infrared Fiber Optic Thermometer/Transmitter ( Voltage Output ) x (T2 - T1) 0-5VDC: Measured Temp = + T1 ( Voltage Output ) x (T2 - T1) 0-10VDC: Measured Temp = + T1 Where, T1 is the minimum temperature range T2 is the maximum temperature range 3.5 - Resetting Temperature Values... -
Page 12: Optical Lens Assembly (L1) .25" @ 8" Fov
OS1592 Infrared Fiber Optic Thermometer/Transmitter FIBER 19 (.75) DIA. 25.4 (1.00) DIA. (4.38) Dimensions mm (in.) (6.25) Figure 5 - Optical Lens Assembly (L1) .25" @ 8" FOV FIBER 19 (.75) DIA. 25.4 (1.00) (4.38) DIA. Dimensions mm (in.) (5.87) Figure 6 - Optical Lens Assembly (L1) .19"... -
Page 13: Polymer Bolt Assembly (L3) With 90° Angle Air Purge Fitting
44.5 (0.75) Dimensions mm (in.) R 17.0 (0.67) 24.6 (0.97) 6.35 (0.25) 4.8 (0.19) 17.5 (0.69) Figure 10 - Optical Head, Mounting Bracket OS1592-MB AIR PURGE INLET (1/8 NPT) 31.8 (1.25) DIA. Dimensions mm (in.) MODEL OS1592-AP1 114.3 mm (4.5") OS1592-AP2 185.4 mm (7.3") -
Page 14: Section 4 Specifications
OS1592 Infrared Fiber Optic Thermometer/Transmitter SPECIFICATIONS Temperature Range 260 to 538°C (500 to 1000°F) 538 to 1093°C (1000 to 2000°F) 1093 to 2482°C (2000 to 4500°F) Accuracy at 22°C (72 °F) 1% of Rdg. ambient temperature and at Emissivity of 0.95 or greater... -
Page 15: Air Purge Collar, Os1592-Ap
OS1592 Infrared Fiber Optic Thermometer/Transmitter Display Backlit LCD dual display Keypad switch 4 position, tactile feed back membrane Electrical Isolation Between Input supply and Analog outputs, 1000 VAC Calculated Temperature Maximum (MAX), Minimum (MIN) values and Differential (DIF), Reset via keypad High Alarm LED &... -
Page 16: Section 5 Maintenance
The ends should be protected from damage, contaminants, and temperatures above 371°C (700°F). OMEGA does not warrant broken or damaged fibers due to mishandling. - Page 17 OS1592 Infrared Fiber Optic Thermometer/Transmitter Addendum Safety Warnings and IEC Symbols This device is marked with international safety and hazardous symbols in accordance with IEC1010. It is important to read and follow all the precautions and instructions in this manual before operating or commissioning this device as it contains important information relating to safety and EMC.
- Page 18 Where Do I Find Everything I Need for Process Measurement and Control? OMEGA…Of Course! Shop online at omega.com TEMPERATURE Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies Wire: Thermocouple, RTD & Thermistor Calibrators & Ice Point References Recorders, Controllers & Process Monitors...
