- Page 1 User’ s Guide Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info WITH BUILT-IN PATENTED LASER CIRCLE SIGHTING OSXL685 and OSXL689 High Performance Infrared Thermometer...
- Page 2 Toll Free in United Kingdom: 0800-488-488 e-mail: sales@omega.co.u k It is the policy of OMEGA Engineering, Inc. to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing certification of its products to the European New Approach Directives.
- Page 3 1-3 Warnings and Cautions 4-4 Advanced Functions 5.PC Interface (OSXL689) 8.Emissivity Table...
- Page 4 Field of View. For large target objects make sure you are within target distance. Patented Laser Circle Sighting 30:1 Field of View - OSXL685 50:1 Field of View - OSXL689 Temperature Data Storage High & Low Audible Alarms...
-
Page 5: Warnings And Cautions
• Use extreme caution when operating the laser sighting. • Never point the laser beam at a person. • Do not attempt to open the thermometer. There are no user serviceable parts. • Keep out of the reach of all children. - Page 6 Read the following instruction manual carefully before attempting to operate the thermometer. Only qualified personnel should perform repairs which are not covered in this manual.
- Page 7 Data Storage Alarms K Type TC TC Input Accuracy USB Port OSXL685 -50 to 1000°C (-58 to 1832°F) From -50 to -20°C (-58 to -4°F) From -20 to 100°C (-4 to 212°F) 100 to -1000°C (212 to 1832°F) 8 to 14 µm Adjustable 0.1 to 1.0...
-
Page 8: Laser Sighting
Complies with 21 CFR Chapter 1, Subchapter J 5 mm <2mrad Dot and Circle Slide switch, ON-OFF Laser icon on display Supplied by the thermometer Located on the right side of the thermometer Located on the left side of the thermometer... - Page 9 To measure a temperature, point the unit at the target, pull the trigger and hold. Make sure the target area is within the field of view of the instrument. The laser circle sighting is used to indicate the perimeter of the instrument’s field of view.
- Page 10 4-3 °C/°F, Laser Switch and Battery Replacement There are two slide switches in front of the battery compartment. One is for °F/°C display and the other is for laser sighting. To change the battery, directly place the battery in the battery compartment.
- Page 11 SCAN mode. If the trigger is released, the unit will go to HOLD mode and will shut itself off after about 6 seconds. The following table shows an overall functional flow chart of the thermometer: Mode Press Mode Key SCAN...
- Page 12 4-4-2 Max, Min, Avg, ∆T Temperature You can review the Maximum, Minimum, Average, and differential (Max - Min) temperatures on the display by pressing the Mode key. If the trigger is pulled at the same time, the display will show SCAN icon and all the values are in real time.
- Page 13 * In Data Record Mode, pressing the M key will record the data in the corresponding memory location. * In Data Recall Mode, you can delete all recorded data by going to DATA o memory location and pressing the M key.
- Page 14 • 5 MB of Disk space After completing the software installation, run the program and connect the thermometer to the PC using the USB port. Turn on the thermometer by pulling the trigger. After a few seconds the PC recognizes the thermometer connection and a USB icon appears on the thermometer’s...
- Page 15 You can determine the recording process by clicking the Stop key. Now you can go back and review the data text file. You can exit the program by clicking the Exit key. Infrared Thermometer 125.6 Record Interval Record Target Temperature °F...
- Page 16 OSXL685 64@2000 2.5@80 OSXL689 20@1000 19@500 0.7@20 0.8@40 D:S = 50:1...
- Page 17 6-2 Emissivity 7. Maintenance PATENT NOTICE: U.S. PAT. B1 5,368,392; 5,524,984; 5,727,880; 5,823,678; 5,823,679; 6,123,453; 6,267,500 B1; 6,341,891 B1; 6,377,400 B1; 6,540,398 B2; 6,614,830 B1; 6,633,434 B2; 6,659,639; 6,901,089 B1 / Canada 2,114,806; 2,317,734 / France 2 756 920; 2 767 921; 2 773 213; 2 773 214 / Germany G 94 22 197.9;...
- Page 18 8. Emissivity Table...
- Page 19 OMEGA’s Customer Service Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any...
