Unique Spares T5206/T5306 - Printronix SL5000 Maintenance Manual

PRINTRONIX T5000 / SL5000 Thermal Printer
Unique Spares T5204/T5304
Spare Spare Part
Level Number
3 171087-001
3 172474-003
3 172197-001
3 171484-003
3 173255-003
3 172142-001
3 171166-001
3 203478-001
9 173603-001
9 173606-001
B. Unique Spares T5206/T5306
Spare Spare Part
Level Number
2 173838-002
2 171404-001
3 750471-002
3 171484-002
3 173255-002
3 175169-002
3 170171-001
3 171624-001
3 178614-002
3 171408-001
3 179269-901
3 170574-002
3 171591-001
3 172474-002
3 171086-002
3 170261-002
3 203479-001
9 173609-001
9 173612-001
PRINTRONIX Confidential Document - Not to be Duplicated.
All prices stated herein are subject to change in accordance with contract terms and conditions
Maintenance Plan Summary
Part Description
Knob, Lead Screw
Peel/Tear Assy, T5XXX, 4 inch, Phase 2
Rack, Gimbal Pivot, 4 inch
Media Guard, Wide, 4 inch
Media Guard, Wide, 4 inch, Phase 3
Shaft, Head Pressure, 4 inch
Shaft, Ribbon Guide, 4 inch
Take up Core, 4 inch
Field Kit, Printhead Assy, 203 DPI, 4 inch
Field Kit, Printhead Assy, 300 DPI, 4 inch
Part Description
Brush Assy, Anti-static, 6 inch
Field Kit, Platen Assy, 6 inch
Beam, Media Hanger, 6 inch
Media Guard, Wide, 6inch
Media Guard, Wide, 6 inch, Phase 3
Damper, Media, 6 inch
Dashpot (Gas Spring), 6 inch
Field Kit, Lower Support Assy, 6 inch
Field Kit, Rewinder Assy, 6 inch, Ver. 3
Field Kit, Ribbon Spindle, 6 inch
Field Kit, Upper Deck Assy, 6 inch
Gimbal, 6 inch, Adjustable
Head Pressure Block Assy, 6 inch (set of 2)
Peel/Tear Assy, T5XXX, 6 inch, Phase 2
Shaft, Head Pressure, 6 inch
Shaft, Ribbon Guide, 6 inch
Take-up Core, 6 inch
Field Kit, Printhead Assy, 203 DPI, 6 inch
Field Kit, Printhead Assy, 300 DPI, 6 inch
(Continued)
List T5X04 T5X06
Price
√
$5.00
√
$221.45
√
$5.00
√
$66.00
√
$17.00
√
$17.82
√
$36.30
√
$5.00
√
$395.00
√
$595.00
List T5X04 T5X06
Price
$16.80
$166.45
$31.32
$66.00
$20.00
$11.40
$42.00
$280.31
$370.17
$185.95
$358.32
$23.00
$162.45
$223.75
$17.34
$40.80
$5.00
$495.00
$695.00
T5X08
T5X08
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
Page 8
