PRINTRONIX T5000 / SL5000 Thermal Printer
The T5000 Series of Printers consists of a family of high quality, Direct Thermal and Thermal Transfer
printers specifically designed for printing labels and tags, from any MS-DOS, Windows, or ASCII based
compatible computer.
The T5000 Thermal Transfer family includes three basic models, T5X04, T5X06 and T5X08. The
model number indicates the print resolution and the print width. For example, a T5206 is a 203 dpi
printer with a 6-inch print width and a T5308 is a 300 dpi printer with an 8-inch print width. The
printhead is interchangeable so that a 203 dpi printer in the field can be easily upgraded to be a 300 dpi
printer, typically by a customer. The printhead is a customer replaceable consumable. 4, 6 and 8-inch
printheads must be used with 4, 6 and 8 inch models. A 6-inch head cannot be mounted in an 8-inch
model and vise versa.
Printer Model
T5204
T5304
T5206
T5306
T5208
T5308
T5000 Thermal Features
Emulations:
provides direct compatibility with Printronix P-series printers. In addition, the printer has co-
resident Printronix IGP/PGL and IGP/VGL emulations which provide printer subsystem
commands for text, barcodes, graphics, lines, and boxes.
T5000r also includes Protocol Interpreters for PPI/ZGL (Zebra), PPI/TGL (TEC), PPI/IPL
(Intermec) and PPI/STGL (Sato).
Hardware Options:
Fonts
resident fonts.
Memory Expansion:
Media Cutter: A Heavy Duty cutter is used to automatically cut printed media.
Label/Tag Catcher Tray: Used with the Media Cutter option to catch the cut media and
collect it away from the Media Cutter Assy.
Internal Label Rewinder: Used for Batch rewind or Peel-Off mode, peels off labels one
at a time before printing the next.
Coax / Twinax Host Interface: Provides connection to an IBM host computer system
using a coax or twinax interface.
PrintNet Servers: Allows the user to attach to a LAN rather than attaching it directly to
a host system.
10/100Base-T (UTP) connection. Wireless 802.11b is also available.
On-Line Barcode Validator: Provides on-line verification of printed barcodes.
The T5000r additional features include a Real Time Clock, USB Communication, GPIO
(General Purpose I/O) and an RFID Upgrade Kit for the T5x4r or T5x6r.
PRINTRONIX Confidential Document - Not to be Duplicated.
All prices stated herein are subject to change in accordance with contract terms and conditions
Maintenance Plan Summary
Max Print Speed
(ips)
10
8
10
8
8
6
The T5000 has the standard Printronix LinePrinter Plus (LP+) emulation which
A selection of fonts is available to extend the capabilities of the standard
16MB DRAM SIMM: Additional memory to accommodate long labels.
10MB Flash SIMM: Additional memory to accommodate IPDS.
The T5000r comes with 32MB DRAM fixed and 8MB Flash upgradeable to
16MB for forms, logos and fonts.
PrintNet servers are available as an internally option with the
Printing Density
(dpi)
203
300
203
300
203
300
Max Print
Width
(inches)
4.1
4.1
6.6
6.6
8.5
8.5
