VIII. T5000, Printronix Recommended Tools
Standard Field Service Tools Including:
Screw Drivers: Flat Tip, ¼ inch blade, Phillips, #1
Pliers: Needle-Nose Pliers, 5 inch,
Hex key, Angled, 2mm, 2.5mm and 3mm
3/16 inch Nut Driver
Feeler gauge set, blade type, with 0.010 inch (0.254mm) and 0.077 inch (1.96mm) gauges
Volt/Ohmmeter
Torque Wrench with ¼ inch hex receptacle and a range of 0-20 inch-pounds, with hex key sizes
2mm and 3mm and #1 Phillips bit.
Loctite 222 thread locker or equivalent
Bearing lubricant, M3 density, P/N 101805-001
Printhead Cleaning Pen (P/N 203502-001) or isopropyl alcohol and cotton swabs
Static Wrist Strap
IX. T5000, Printronix Recommended Field Spares (U.S. Prices)
The recommended spares list, including applicable repair pricing are attached in the following pages for
reference information and planning. Spares may be ordered by contacting the Printronix Order Entry
Department:
Irvine, CA
Wijchen, Holland
Singapore
A. Unique Spares T5204/T5304
Spare Spare Part
Level Number
2 173858-001
2 171774-001
2 172261-001
3 178496-003
3 172151-001
3 175169-003
3 170171-003
3 171089-001
3 171892-003
3 172270-001
3 178614-003
3 172264-001
3 178624-901
3 171161-001
3 171088-001
PRINTRONIX Confidential Document - Not to be Duplicated.
All prices stated herein are subject to change in accordance with contract terms and conditions
Maintenance Plan Summary
(714) 368-2464
(31) 24 6489 489
(65) 6548-4182
Part Description
Brush Assy, Anti-static, 4 inch
Cable Assy, Printhead to Controller, T5X04
Field Kit, Platen Assy, 4 inch
Beam, Media Hanger 4 inch
Cover, Media, 4 inch (Powder Coated)
Damper, Media, 4 inch
Dashpot (Gas Spring), 4 inch
Dial, Head Pressure Adjustment, for lrg knob
Door, Peel/Tear 4 inch new
Field Kit, Lower Support Assy, 4 inch
Field Kit, Rewinder Assy, 4 inch V-3
Field Kit, Ribbon Spindle, 4 inch
Field Kit, Upper Deck Assy, 4 inch
Gimbal, 4 inch, T5XXX
Indicator, Head Pressure Dial
12R Internal Snap Ring Pliers
List
Price
$31.80
$12.00
$84.30
$26.16
$290.88
$10.50
$38.64
$5.00
$87.00
$190.80
$357.45
$82.05
$313.88
$22.50
$5.00
