QuickSpecs
E
U
A S E O F
S E
(continued)
MAC Address Labels
IBM 16/4 Token Ring PCI Special Adapter has a MAC address label on the outside of the bracket to make network troubleshooting easier.
Conformance to Industry Standards
The IBM 16/4 Token Ring PCI Special Adapter is fully compatible with Windows NT and Microsoft's PC98/PC99 networking standards. Additionally, the
IBM 16/4 Token Ring PCI Special NIC is Novell NetWare certified.
S
P E C I F I C A T I O N S
Compliance
General Specifications
Operating System Support
Power and Environmental
Specifications
Kit Contents
DA-10309
Division — Version 04 — January 22, 2001
Basic Token Ring (IEEE 802.5)
Dedicated Token Ring (IEEE 802.5R)
PCI 2.2 and 2.1
Wake on LAN (WOL)
16/4 Mbps
16K transmit & 4K receive buffer memory
PCI Hot Plug for Novell NetWare
5V
DTR for full-duplex support
Bus mastering
Boot ROM socket
UTP/STP support with RJ-45 and DB9 ports
Microsoft Windows 2000
Note: Drivers on Microsoft Windows 2000 Operating System CD
Microsoft Windows NT 4.0
Windows NT 3.51
Novell NetWare 5.x Server
Novell NetWare 4.x Server
Novell NetWare 3.x Server
SCO UnixWare 7.x
SCO OpenServer 5.x
Microsoft Windows 98
Microsoft Windows 95
Microsoft Windows for Workgroups 3.11
NetWare DOS Client
MS DOS Client
OS/2 Warp 4
Operating
Temperature
Humidity
Non-operating
Temperature
Humidity
Power Requirements
5V dc/1.5W maximum
Emissions Standard
FCC Class A
Safety Compliance
FCC Class B
Note: Shielded Power Cord is required to meet this requirement.
IBM 16/4 Token Ring PCI Special NIC
WOL cable for PCI 2.1 WOL systems
CD that includes Drivers, User's Guide, and Installation and Diagnostic Utility
Quick Install Card
Quality Statement
IBM 16/4 Token Ring PCI Special NIC
50° to 95°F/10° to 35°C
8% to 80% (non-condensing)
–22° to 140°F/–30° to 60°C
5% to 90% (non-condensing)
2
