Tripp Lite NetDirector B022-U16 Quick Start Manual

Quick Start Guide
NetDirector Console KVM Switch
(8- or 16-Port)
or Rackmount KVM Switch (16-Port)
Models: B020-U08-19-K, B020-U08-19KTAA, B020-U16-19-K or B022-U16
This Quick Start Guide will take you through basic installation, configuration and local
operation. For more detailed information, refer to the Owner's Manual on the CD-ROM.
This Package Should Consist Of:
• (1) B020-U08-19-K, B020-U08-19KTAA, B020-U16-19-K or B022-U16 KVM Switch
• (8) P778-006 USB/PS2 Combo KVM Cable Kits*
• (2) P778-006 USB/PS2 Combo KVM Cable Kits**
• (1) USB/PS2 Combo Console Cable Kit
• (1) RJ45 to DB9 Firmware Upgrade Cable
• (1) C13 to 5-15P Power Cord*
• (1) AC Power Adapter (Input: 100-240V, 50/60 Hz, 0.5A/Output: 5.3V, 2.4A)**
• (1) CD with Owner's Manual
• (1) Quick Start Guide
• (1) Grounding Wire
• (1) Rackmount Hardware Kit
• (1) Set of Rubber Feet**
*B020-U08-19-K, B020-U08-19KTAA or B020-U16-19-K only
**B022-U16 only
Check to see that the unit arrived undamaged, with all of its contents. Contact your dealer if
there is a problem.
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
