K1
K2
INPUTS
AUX
AUDIO
+24V DC
IN
OUT
AUDIO CC
VIP-201 (REAR VIEW)
VALCOM
-24Vdc
POWER SUPPLY
24VDC
AC
-
+
Ground
WHITE-BLUE / BLUE PAIR
TIP
VALCOM
RING
WHITE-ORANGE / ORANGE PAIR
SELF-AMPLIFIED
GND
SPEAKER
WHITE-BROWN / BROWN PAIR
-24Vdc
WHITE-GREEN / GREEN PAIR (UNUSED)
CAT 3/5/5e/6 CABLE
Typical Connection to Valcom Self-amplified Speakers
4
