TO REMOVE COVER
LOOSEN SCREW,
THEN ACTIVATE LATCH
PLASTIC
COVER
WIREWAY OPENING
TO WALL PLATE AND
JUNCTION BOX
METAL WALL
MOUNTING
PLATE
SNAP LATCH
CIRCUIT BOARD
HOUSING ASSEMBLY
BRACKET
LOCKING
SCREW
FIGURE A
3
WIRE TIE LOOP
WIRE TIE USED TO BUNDLE WIRES
ENTERING AND LEAVING TERMINAL AREA
.155 DIA. HOLES FOR MOUNTING TO
SINGLE OR DOUBLE GANG JUNCTION BOX
HOLE PATTERN MATCHES BOTH EURO
AND US JUNCTION BOXES
1.5 x 2 WIRE ACCESS OPENING
TO JUNCTION BOX
SNAP LATCH
FOR COVER
947291
