- Page 1 For the qualified engineer Installation instructions Control Center VR 65 Control Center for storage connection (eBUS) VR 65...
-
Page 3: Table Of Contents
Accessories ....... . 5 Please pass on this installation manual to the owner of Assembling Control Center VR 65 ... . 6 the system so that he can keep it available whenever it is required. -
Page 4: Data Badge
230 V cylinder thermostat. This will then allow the cylinder temperature to be set at Danger! the Vaillant ecoTEC boiler or at the Vaillant VRT 360 or Risk of death from electric shock through con- VRC 400 control. -
Page 5: Installation 4
DHW cylinder. The hot water and heating programs as and hot water. well as all required parameters are set at the VRT 360 Designed to plug into the Vaillant ecoTEC boiler or for or VRC 400. All heating circuit connections are made at wall mounting. -
Page 6: Assembling Control Center Vr 65
N on 230 V~ Fig. 4.2 Assembling the Control Centers eBUS connection Operating LED Fig. 5.1 Connection of eBUS and mains cable in the system 2 Fixing holes 3 Cable clamps 4 On/Off switch Installation Instructions for Control Center VR 65... -
Page 7: Installing The Vr 65 With One 3-Port Valve
230 V~ (VRT 360 or VRC 400) * Cylinder thermostat 230 V~ * Note: With Vaillant uniSTOR - use either the cylinder thermostat or the NTC Fig. 5.2 Connection with 3-port valve Installation Instructions for Control Center VR 65... -
Page 8: Installing The Vr 65 With Two 2-Port Valves
230 V~ (VRT 360 or VRC 400) * Cylinder thermostat 230 V~ * Note: With Vaillant uniSTOR - use either the cylinder thermostat or the NTC Fig. 5.3 Connection with two 2-port valves Installation Instructions for Control Center VR 65... -
Page 9: Installing The Vr 65 With A Ntc
Installing the VR 65 with a NTC Note! To comply with the approvals, the boiler must be Vaillant ecoTEC if the cylinder NTC solution is used. Before installing the NTC, first remove the cylinder con- trol with two capillary tubes for the cylinder thermostat and thermal cut out. -
Page 10: Start-Up
• Use the ‚+‘ and ‚-‘ keys to scroll to the diagnostic point d.70 • Press the “i” key. The Control Center VR 65 has a green Operating LED, Change the setting using the ‚+‘ and ‚-‘ keys. which can be monitored when the housing cover is •... -
Page 11: Factory Customer Service 8
Minimum cross-section of the power supply cable (rigid cable, NYM) Maximum ambient temperature °C Housing dimensions Height Width Depth Level of protection IP 20 Protection class Table 9.1 Technical data Installation Instructions for Control Center VR 65...
