Wells WFPE-30F Parts List

Free-standing pressure fryers
Hide thumbs Also See for WFPE-30F:

Advertisement

Quick Links

Download this manual See also: Operating Manual, Installation, Operation & Maintenance Manual
30# FREE-STANDING PRESSURE FRYERS
Description

Parts List ...........................................................

Cabinet Components ............................................
Yoke & Lid Components ........................................
Pressure System Exhaust Components ..................... 5
Electrical Components ..........................................
Filter Pump & Wand Components ...........................
Accessories & Removable Components ....................
PL362
p/n
Rev. B
2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439
PARTS LIST
PL362
WFPE-30F
CONTENTS
PRINTED IN UNITED STATES OF AMERICA
WELLS BLOOMFIELD, LLC
telephone: 775-689-5703
fax: 775-689-5976
www.wellsbloomfield.com
362
page
2
3
4
6
7
8
08
0311 cps

Advertisement

loading
Need help?

Need help?

Do you have a question about the WFPE-30F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wells WFPE-30F

Summary of Contents for Wells WFPE-30F

  • Page 1: Parts List

    WELLS BLOOMFIELD, LLC 2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439 telephone: 775-689-5703 fax: 775-689-5976 www.wellsbloomfield.com PARTS LIST PL362 30# FREE-STANDING PRESSURE FRYERS WFPE-30F CONTENTS Description page Parts List ………………………………………………….. Cabinet Components ………………………….….……… Yoke & Lid Components ……………………….…………...
  • Page 2 PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION OPTIONAL ACCESSORIES MECHANICAL HARDWARE, etc. 21646 CASTER RIGID 5” (PK 2) 61713 DOOR ASSEMBLY, WFAE30/WFPE30 50177 FIBER WASHER 1/2 NPT x .031T 21647 BRUSH, ELEMENT CLEANING 42504 CLAMP, SAFETY BULB FRYER (pk 4) 51040 BUSHING, HEYCO 7/8 OD 21711...
  • Page 3 WFPE-30F CABINET COMPONENTS BUSHING, SLIDE 66753 GUARD 500527 FACEPLATE 502391 CLAMP, TOP FRYER 67332 (2 places) TUBE, SILICONE .375 IDx 24-1/4” MAGNET, DOOR 8706-21 66502 FITTING, SUCTION LINE 66720 ASSEMBLY, DOOR 61713 (includes 51973 HANDLE) HANDLE, DOOR (only) 51973 CASTER, RIGID 5”...
  • Page 4 WFPE-30F YOKE & LID COMPONENTS CAP, YOKE 67017 SCREW, 1/4-20 x1/2 SOC CAP 67058 (pk 2) KIT, YOKE ASSY REPLACEMENT PLATE, PISTON TOP 501041 (CAM FOLLOWER) 66776 YOKE & HANDLE ASSEMBLY 66783 BEARING, YOKE 66906 HOLE PLUG 1/2” Ni 54282 (pk 4)
  • Page 5 WFPE-30F PRESSURE SYSTEM EXHAUST COMPONENTS CONTROL ROD/ COOK LEVER ASSEMBLY 66907 SPOUT, CONDENSATE 67081 O-RING, EXHAUST VALVE 66651 EXHAUST VALVE 66782 INSULATOR MICROSWITCH SLEEVE, EXHAUST 67085 LINE 69728 MICROSWITCH 64887...
  • Page 6 WFPE-30F ELECTRICAL COMPONENTS INSULATOR MICROSWITCH 67085 MICROSWITCH 64887 SWITCH FRY/OFF/FILTER 69550 LIGHT, SIGNAL AMBER 50516 (3 places) TIMER ASSEMBLY 68248 ELEMENT, HEATING 208V 9000W 66664 ELEMENT, HEATING 240V 9000W 66691 SAFETY CLAMP ELEMENT, 502332 (6 places) GASKET, ELEMENT 66863 CONTACTOR...
  • Page 7 WFPE-30F PUMP AND WAND COMPONENTS CHECKVALVE 3/8 NPT FEMALE x FLEX LINE, DISCHARGE MOTOR, FILTER 3/8 NPT MALE .6” OD x 9.5” LONG 1ø 125/230v 50/60 Hz 66692 502289 501205 WASHER, FIBER 50177 PUMP, FILTER 501231 FRYPOT INLET DRAIN VALVE...
  • Page 8 WFPE-30F ACCESSORIES & REMOVEABLE COMPONENTS PADDLE, STIRRING CHICKEN 22515 BRUSH, CLEANING FRYER (HI-TEMP) 22516 BRUSH, CLEANING BASKET HANDLE ELEMENT 21647 500249 DOWEL, CLEANOUT FRYER 69752 FRY BASKET (STD) 22685 FILTER PAPER HOLDER 66744 BASKET RACK 66757 FILTER PAPER 21711 (pk 100)
  • Page 9 NOTES...
  • Page 10 Commercial Food Equipment Service Association Wells Bloomfield proudly supports CFESA Commercial Food Equipment Service Association SERVICE TRAINING - QUALITY SERVICE SERVICE TRAINING - QUALITY SERVICE Genuine Parts Protect - YOU - All - Ways CUSTOMER SATISFACTION CUSTOMER SATISFACTION WELLS BLOOMFIELD, LLC 2 ERIK CIRCLE, P.
