WVFG VENTLESS FRYER/GRIDDLE
WITH OR WITHOUT ROLL WARMER
Description
Parts List ...........................................................
WVFG Hood Section
Cabinet .........................................................
Hood Electrical and Vacuum ..............................
WVFG Griddle Section .........................................
WVFG Fryer Section ............................................
WV-FGRW Roll Warmer Section .............................
Ansul© Fire Detection & Suppression ......................
PL507
p/n
Rev. D
2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439
PARTS LIST
PL507
CONTENTS
PRINTED IN UNITED STATES OF AMERICA
WELLS BLOOMFIELD, LLC
telephone: 775-689-5703
fax: 775-689-5976
www.wellsbloomfield.com
507
page
2
4
5
6
8
9
10
08
0602 cps
