- Page 1 Radio Navigation Chicago 600 Operating instructions...
- Page 2 Controls MENU button Reset button Call up main menu Restoring the original factory settings of the device. In the main menu: Call up menu of active source Caution! All personal settings will be lost! MAP button Cover Call up navigation SD card reader In navigation mode: Call up menu of active source Access only with open cover...
-
Page 3: Table Of Contents
Contents Safety notes ..............4 Sound settings ............16 Symbols used ................4 Volume distribution (fader/balance) ......16 Road safety ................4 Equalizer .................. 16 General safety notes ..............4 Basic settings ............17 Declaration of conformity ............4 General ..................17 Cleaning notes ............4 Time .................. -
Page 4: Safety Notes
In addition, observe the instructions of the devices used Declaration of conformity in conjunction with this car sound system. We, Blaupunkt AudioVision GmbH & Co. KG, affi rm that the device Chicago 600 fulfi ls the fundamental require- Symbols used... -
Page 5: Scope Of Delivery
In the main menu, you press the buttons on the touch- The scope of delivery includes: screen to call up the diff erent sources and operating • Chicago 600 modes. • TMC Tuner (for 1 011 103 600 only) u Press the MENU button •... -
Page 6: Storing Stations Manually
Radio mode Enter broadcast frequency directly Switching RDS on/off If the frequency of the desired stations is known, it can Many FM stations broadcast an RDS (Radio Data System) be entered directly via the touchscreen. signal in addition to their programme in the reception u In radio mode, press the [ ] button. -
Page 7: Navigation
Download of map data To ensure that you have the latest version of the map data when you purchase the Chicago 600, you have 30 days from the fi rst GPS positioning to download the latest version of the map data once and free of charge to the standard MicroSD card from the Internet at www.naviextras.com. -
Page 8: Points Of Interest
Navigation The menu for the address entry is displayed. After the route calculation is complete, the param- eters of the route, such as distance and time, are displayed. In addition, the entire route is displayed on the map. u Enter the country, city and street in succession as well as the intersection or house number. -
Page 9: Setting Route Options
Navigation A list of petrol stations in the vicinity of the vehicle is Adjusting route options before the route guidance u Call up the navigation menu. displayed. The petrol stations are sorted by distance to vehicle. u Press More…. u Select a petrol station from the list by pressing on the u Press Settings. -
Page 10: Map Settings
Navigation Changing route options during route guidance The map settings are displayed. u During a route guidance, press the More button. u Change the settings, if necessary. u Press Route Settings. u Press Back repeatedly until the navigation menu is displayed again. -
Page 11: Usb/Sdhc/Ipod Media Playback
Basic information u Insert the USB data carrier in the USB socket The Chicago 600 can be used to play MP3 or WMA fi les on USB data carriers and SDHC cards. The device automatically switches to USB1 mode. -
Page 12: Audio Playback Of Usb, Sdhc Or Ipod/Iphone
USB/SDHC/iPod media playback Audio playback of USB, SDHC or ] Start REPEAT function: iPod/iPhone After a single press, the repeat function for the current title is active. The button is high- The principles of the audio playback (MP3/WMA) from lighted and a 1 is shown on the button. data carriers or iPod®/iPhone®... -
Page 13: Image Playback From Usb Or Sdhc
USB/SDHC/iPod media playback The playback menu is shown. Image playback from USB or SDHC u Select the desired source via the main menu. If the playback starts with audio or movie fi les, u press the [ ] button to change to the image play- back. -
Page 14: Bluetooth Mode
Bluetooth mode Registering Bluetooth devices Bluetooth mode If you want to register a device with the Chicago 600 for The Bluetooth® function allows registering cell phones the fi rst time, proceed as follows: and media playback devices with the Chicago 600. -
Page 15: Bluetooth Settings
Bluetooth mode | Rear Seat Entertainment If a call is coming in, the call menu is displayed. Rear Seat Entertainment (RSE) The Chicago 600 features outputs to connect two exter- nal monitors and audio outputs for the rear area of the vehicle. -
Page 16: External Audio/Video Sources
External audio/video sources | Sound settings External audio/video sources Sound settings This device features two external AV inputs for audio and Volume distribution (fader/balance) video playback: You can adjust the volume distribution in the vehicle • AV-IN 1 is located under the cover at the front of the for all sources. -
Page 17: Basic Settings
In the settings menu of the device, you can adjust the basic settings for the diff erent functions of the Chicago 600 to your requirements. u In the main menu, press the Settings button. The settings menu is displayed, the General sub- menu is activated. -
Page 18: Language
The following setting is possible: The following settings are possible: On screen display – Language for the user interface of Aspect ratio – Adjust image format the Chicago 600. Rear view camera – Adjust back-up camera (if a back-up camera is connected) Bluetooth... -
Page 19: Useful Information
European Union, the warranty terms issued by our respective responsible domestic agency are valid. The warranty terms can be called up from www.blaupunkt.com. Service If you ever need to use a repair service, you will fi nd in- formation about service partners in your country under www.blaupunkt.com. -
Page 20: Connection Diagram
Connection diagram... -
Page 21: Appendix
Microsoft. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. © 2011 All rights reserved by Blaupunkt. This material may be reproduced, copied or distributed for personal use only. - Page 22 Blaupunkt AudioVision GmbH & Co. KG Robert-Bosch-Straße 200 D-31139 Hildesheim http://www.blaupunkt.com 04/11...
